Dell PowerEdge R830
Dell PowerEdge R830 Available to Quote:

Dell PowerEdge R830






 Request a Quote
Description Specifications Additional materials

Dell PowerEdge R830

General All
Interfaces
1
Serial interfaces: 1
Videointerfaces: 2-Port VGA
Expansion slots: 7 slots PCIe
Network interfaces:
  • 4-Port 1GbE (RJ45);
  • 2-Port 1GbE (RJ45) + 2-Port 10GbE (RJ45);
  • 2-Port 1GbE (SFP) + 2-Port 10GbE (SFP+)
USB ports:
  • 2-Port USB (front panel);
  • 2-Port USB (rear panel);
  • 1-Port USB (internal)



2
Physical Parameters
3
Dimensions (HxWxD) (mm)
86.8 (2U) x 482.4 х 811.06
(3.417 (2U) x 18.89 x 31.93 in)
4
Maximum Weight (kg)

31.7 (69.89 lb)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

10 to 35 (50 to 95°F)

8
CPU
9
Quantity: 4
Series: Intel Xeon E5-4600 v4
10
Memory
11
Type: DDR4 RDIMM, LRDIMM
Number of slots: 48
Maximum capacity: 3 TB (48 x 64 GB)
12
Storage
13
Chassis with 16 HDD 2.5":
  • 14 TB (16 x 900 GB SAS);
  • 16 TB (16 x 1.0 TB SATA)
14
Power Supply Unit (PSU)
15
AC PSU
Power capacity (W):
750; 1600
Type:
Removable
Quantity:

750W:
1600W:
2
Rated voltage range:
100 to 240 VAC, 50-60 Hz



16
DC PSU

Not supported

17

R830 Datasheet (en)
