HPE MSA 2042 SAN Storage
HPE MSA 2042 SAN Storage Available to Quote:

HPE MSA 2042 SAN Storage

 Request a Quote
Description Specifications Additional materials
General All
Interfaces
1
Network interfaces:
  • 4-Port 8GbE (SFP) FC;
  • 4-Port 16GbE (SFP) FC;
  • 4-Port 10GbE (SFP+) iSCSI;
  • 4-Port 1GbE (SFP) iSCSI;
  • 4-Port 12GbE (SFF-8644) SAS
2
Physical Parameters
3
Dimensions (HxWxD) (mm)

LFF Controller:
89 (2U) x 482.6 x 572
(3.5 (2U) x 19 x 22.5 in)

SFF Controller:
89 (2U) x 482.6 x 495
(3.5 (2U) x 19 x 19.5 in)
LFF Disk Enclosure:
89 (2U) x 482.6 x 572
(3.5 (2U) x 19 x 22.5 in)
SFF Disk Enclosure:
89 (2U) x 482.6 x 495
(3.5 (2U) x 19 x 19.5 in)



4
Maximum Weight (kg)
LFF Controller Enclosure: 18.42 (40.6 lb)
SFF Controller Enclosure: 17.6 (38.7 lb)
LFF Disk Enclosure: 18.42 (40.6 lb)
SFF Disk Enclosure: 17.6 (38.7 lb)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 40

7
Operating Temperature (°C)

10 to 90 (41 to 104°F)

8
9
Storage
10
LFF Controller Enclosure with 12 HDD 3.5":
  • 144 TB (12 x 12 TB LFF SAS MDL);
  • 1152 TB (with 7 LFF Disk Enclosures)
SFF Controller Enclosure with 24 HDD 2.5":
  • 76.8 TB (24 x 3.2 TB SFF SSD);
  • 637 TB (with 7 SFF Disk Enclosures)
LFF Disk Enclosure with 12 HDD 3.5":
  • 144 TB (12 x 12 TB LFF SAS MDL)
SFF Disk Enclosure with 24 HDD 2.5":
  • 76.8 TB (24 x 3.2 TB SFF SSD)



11
Power Supply Unit (PSU)
12
AC PSU

2 x 500 W

13
DC PSU

Not supported

14

MSA 2042 Datasheet (en)
