Huawei OceanStor 5300F/5500F
Huawei OceanStor 5300F/5500F Available to Quote:
Huawei OceanStor 5300F V5;
Huawei OceanStor 5500F V5
 Request a Quote
Description Specifications Additional materials
General All
Interfaces
1

Network interfaces:
  • 4-Port 1GbE (SFP);
  • 4-Port 10GbE (RJ45);
  • 4-Port 8GbE (SFP) FC;
  • 8-Port 8GbE (SFP) FC;
  • 8-Port 16GbE (QSFP+);
  • 2-Port 10GbE FCoE;
  • 2-Port 40GbE (QSFP28);
  • 2-Port 100GbE (QSFP28);
  • 4-Port 12GbE (SAS 3.0);
  • 4-Port 10GbE Smart I/O (8GbE / 10GbE / 16GbE);
  • 2-Port 56GbE (InfiniBand interface module)



2
Physical Parameters
3
Dimensions (HxWxD) (mm)

Controller Enclosure:
86,1 (2U) х 447 х 750
(3,38 х 17,59 х 29,52 in)
Disk Enclosure:
86,1 (2U) x 447 x 490
(3,38 x 17,59 x 19,29 in)
4
Maximum Weight (kg)

Controller Enclosure:

 37 (81,57 lb)
Disk Enclosure: 20 (44,09 lb)



5
Environmental Conditions
6
Relative Humidity (%)

5 to 90

7
Operating Temperature (°C)

5 to 40 (41 to 104°F)

8
9
Storage
10
Maximum controllers: 8
Maximum disks SSD 2,5":
OceanStor 5300F V5: 750 (25 х 2,5" expansion shelves)
OceanStor 5500F V5: 1000 (25 х 2,5" expansion shelves)
11
Power Supply Unit (PSU)
12
AC PSU

2 x 800 W

13
DC PSU

2 х 800 W

14

Datasheet 5300F / 5500F V5 (en)
