Server HPE ProLiant DL360 Gen10 Available to Quote:

HPE ProLiant DL360 Gen10

Request a Quote
Description Specifications Additional materials
General All
Interfaces
1
Serial interfaces: 1
Videointerfaces: 2-Port VGA (1 on the rear panel, 1 on the front panel (optional))
Expansion slots:
  • 2 slots PCIe 3.0 x8;
  • 1 slot PCIe 3.0 x16;
  • 1 slot FlexibleLOM
Network interfaces:

2 network cards.

Supported interfaces:

  • 4-Port 1GbE (SFP);
  • 1-Port management (RJ45)
MicroSD slots: 1
USB ports:
  • 1-Port USB (front panel);
  • 2-Port USB (rear panel);
  • 2-Port USB (internal)



2
Physical Parameters
3
Dimensions (HxWxD) (mm)

42,9 (1U) x 434,6 х 749,8

4
Maximum Weight (kg)

16,78

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

10 to 35 (50 to 95°F)

8
9
CPU
10
Quantity: 2
Series: Intel Xeon Scalable 8100/8200



11
Memory
12
Type: DDR4 RDIMM / LRDIMM
Number of slots: 24
Maximum capacity: 6,0 TB (12 х 512 GB)
Maximum capacity LRDIMM: 3 ТB (24 x 128 GB)
Maximum capacity RDIMM: 1,54 GB (24 x 64 GB)
Maximum capacity NVDIMM: 192 GB (12 x 16 GB)



13
Storage
14
Hot Plug SFF SAS HDD 26,4 ТB (8+2 + 1 x 2,4 ТB)
Hot Plug SFF SATA HDD 22 ТB (8+2+1 x 2,0 ТB)
Hot Plug SFF SAS SSD 168,3 ТB (8+2+1 x 15,3 ТB)
Hot Plug SFF SATA SSD 42,24 ТB (8+2+1 x 3,84 ТB)
Hot Plug SFF NVMe PCIe SSD 153,6 ТB (10 x 15,36 ТB NVMe)
Hot Plug LFF SAS HDD 56 ТB (4 х 14 ТB)
Hot Plug LFF SATA HDD 56 ТB (4 x 14 ТB)
Hot Plug LFF SAS SSD 7,68 ТB (4 x 1,92 ТB)
Hot Plug LFF SATA SSD 7,68 ТB (4 x 1,92 ТB)



15
Power Supply Unit (PSU)
16
AC PSU
  • 1 x 500 W
  • 1 x 800 W
17
DC PSU
  • 1 x 1600 W
18
