FusionServer 5288 V5

Request a Quote

Description Specifications Additional materials

Huawei FusionServer Pro 5288 V5 is a rack server in the 4U form factor. FusionServer Pro 5288 V5 supports up to 2 powerful Intel Xeon processors, 24 DDR4 DIMMs, and up to 24 HDD.

General All

Interfaces

Serial interfaces:	1
Videointerfaces:	1-Port VGA
Expansion slots:	1 slot PCIe 3.0 x16 of full-height; 1 slot PCIe 3.0 x8 of full-height full-length; 1 slot PCIe 3.0 x8 of full-height half-length; 2 slots PCIe 3.0 x8 of half-height half-length
Network interfaces:	1 network card. Supported interfaces: 2-Port 1GbE (RJ45); 4-Port 1GbE (RJ45); 2-Port 10GbE (SFP+); 2-Port 10GbE (RJ45); 2-Port 1GbE (RJ45) and 2-Port 10GbE (SFP+).
USB ports:	2-Port USB 2.0 (front panel) 2-Port USB 3.0 (rear panel)

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

175 (4U) x 447 х 748

(6.89 (4U) x 17.60 x 29.45)

Maximum Weight (kg)/(lbs)

48 (105.82)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)/(°F)

5 to 40 (41 to 104)

CPU

Quantity:	1 or 2
Series:	Intel Xeon E5-2600 v3/v4

Memory

Type:	DDR4 RDIMM / LRDIMM
Number of slots:	24
Maximum capacity:	3 TB (24 x 128 GB)

Storage

Chassis with 24 HDD:

Front panel:

Rear panel:

21.6 TB (12 x 1.8 TB SAS);
48 TB (12 x 4 TB NL SAS);
96 TB (12 x 8 TB SATA);
19.2 TB (12 x 1.6 TB SSD)

Optional internal disks: 4 x 2.5" / 3.5" SAS / NL SAS / SATA / SSD HDD

Power Supply Unit (PSU)

AC PSU

Power capacity (W):	900; 1500
Type:	Removable
Quantity:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Power capacity (W):	1500
Type:	Removable
Quantity:	2
Rated voltage range:	-48 to -60 VDC

FusionServer 5288 V5 Datasheet (en)
