Firewall Juniper SRX1500 Series

Firewall Juniper SRX1500 Series Available to Quote:

SRX1500

Request a Quote

Description Specifications Additional materials

Juniper SRX1500 is a high-performance firewall which provides reliable protection for data centers and campus networks.

SRX1500 is designed in compact 1U form factor chassis with fixed 1GbE, 10GbE ports. SRX1500 has firewall performance up to 10 Gbit/s and IPSec VPN performance up to 4 Gbit/s.

The SRX1500 firewall support various security features, as well as routing and switching.

General All

Interfaces

SRX1500:

12-Port 1GbE (RJ45);
4-Port 1GbE (SFP);
4-Port 10GbE (SFP+);
1-Port USB;
2 PIM cards expansion slots;
1 SSD slot;
1-Port out-of-band management 1GbE (RJ45);
1-Port console (RJ45)/(miniUSB)

Physical Parameters

Dimensions (HxWxD) (mm)

44.4 (1U) x 444.5 x 462.2

(1.75 (1U) x 17.5 x 18.2 in)

Maximum Weight (kg)

7.30 (16.1 lbs)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)

0 to 40 (32 to 104 °F)

Maximum Power Consumption (W)

150

Performance

Firewall throughput IMIX (Gbit/s):	5
Firewall throughput (64 Byte) (Mp/s):	1.7
Maximum concurrent sessions:	2,000,000
Connections per second:	50,000
Maximum security policies:	16,000
IPsec VPN tunnels:	2000
IPS throughput (Gbit/s):	3
Application Control throughput (Gbit/s):	1.5

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz.

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-48 to -60 VDC

Compatible Expansion Cards

Not supported

SRX1500 Datasheet (en)
