Fortinet FortiGate 200D Series

End-of-Sale

Please see "Similar Products" below.



Description Specifications Additional materials
The FortiGate 200D is the next generation of compact firewalls for medium and large enterprises with the ability to deploy on campus or branch office.

The FortiGate 200D Series offers extensive routing, switching, and scalable IPsec VPN capabilities to integrate network and security.

FortiGate 200D gateways provide flexible deployment of SD-WAN, reliable protection against cyber threats using the security processor SPU. They also protect against malicious programs and websites in an encrypted and unencrypted form, and detect attacks using continuous analysis.

General All
Interfaces
1
FortiGate 200D:
  • 18-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 16-Port LAN);
  • 2-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45);
  • 64GB SSD local storage
Fortigate 200D-POE:
  • 18-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 8-Port LAN; 8-Port POE);
  • 2-Port 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45)
  • 64GB SSD local storage
FortiGate 240D:
  • 42-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 40-Port LAN);
  • 2-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45);
  • 64GB SSD local storage
FortiGate 240D:
  • 42-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 16-Port LAN; 24-Port PoE);
  • 2-Port 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45);
  • 64GB SSD local storage
FortiGate 240D:
  • 86-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN; 52-Port LAN; 32-Port PoE);
  • 4-Port DMZ 1GbE (SFP);
  • 1 Port USB;
  • 1-Port console (RJ45);
  • 64GB SSD local storage
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
FortiGate 200D:
FortiGate 240D:
44 (1U) x 432 х 298
(1.75 (1U) x 17.01 x 11.73 in)
Fortigate 200D-POE:
FortiGate 240D:
44 (1U) x 432 х 334
(1.75 (1U) x 17.01 x 13.14 in)
FortiGate 240D:
90 (2U) x 437 х 300
(3.5 (2U) x 17.2 x 11.8 in)
4
Maximum Weight (kg)
FortiGate 200D:
FortiGate 240D:
4.8 (10.5 lbs)
Fortigate 200D-POE:
5.7 (12.6 lbs)
FortiGate 240D:
6.0 (13.2 lbs)
FortiGate 240D:
7.6 (17.0 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

20 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)
FortiGate 200D: 83
Fortigate 200D-POE: 205
FortiGate 240D: 99
FortiGate 240D: 375
FortiGate 240D: 418
9
Performance
10
Firewall throughput (Gbit/s):
Fortigate 200D:
Fortigate 200D-POE:
3
Fortigate 240D:
Fortigate 240D-POE:
Fortigate 280D-POE:
4

Firewall throughput (Mp/s):
Fortigate 200D:
Fortigate 200D-POE:
4,5
Fortigate 240D:
Fortigate 240D-POE:
Fortigate 280D-POE:
6

Maximum concurrent sessions:
3.2M

Connections per second:
77,000

Maximum security policies:
10,000

IPsec VPN throughput (Gbit/s):
1.3

IPsec VPN tunnels:
5000

IPS throughput (Gbit/s):
Fortigate 200D:
Fortigate 200D-POE
1.7
Fortigate 240D:
Fortigate 240D-POE:
Fortigate 280D-POE:
2.1

Application Control throughput (Gbit/s):
600
11
Power Supply Unit (PSU)
12
AC PSU
Type: Built-in
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU

Not supported

14
Compatible Expansion Cards
15

Not supported
