Fortinet FortiGate 200E Series Available to Quote:

FortiGate 200E

FortiGate 201E

Request a Quote
Description Specifications Additional materials

The FortiGate 200E is the next generation of firewalls for mid-sized and large enterprises that provides extensive routing, switching, wireless controller capabilities, and scalable IPsec VPN capabilities to combine network and security functions.

FortiGate 200E gateways provide flexible SD-WAN deployment, robust threat protection, and low latency using a security processor (SPU). They protect against encrypted and unencrypted malware, vulnerabilities and malicious websites, and they detect attacks using continuous analysis.

General All
Interfaces
1
FortiGate 200E:
  • 4-Port 1GbE (SFP);
  • 14-Port 1GbE (RJ45);
  • 2-Port 1GbE (RJ45) WAN;
  • 2-Port MGMT/HA 1GbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1-Port RPS;
FortiGate 201E:
  • 4-Port 1GbE (SFP);
  • 14-Port 1GbE (RJ45);
  • 2-Port 1GbE (RJ45) WAN;
  • 2-Port MGMT/HA 1GbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1-Port RPS;
  • 480 GB SSD local storage
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
44.45 (1U) x 432 х 301 mm
(1.75 (1U) x 17.0 x 11.9 in)
4
Maximum Weight (kg)
FortiGate 200E: 5.4 kg (11.9 lbs)
FortiGate 201E: 5.5 kg (12.12 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
FortiGate 200E: 70.98
FortiGate 201E: 109.9
9
Performance
10
Firewall throughput (64 Byte) (Gbit/s): 9
Firewall throughput (Mp/s): 13.5
Maximum concurrent sessions: 2M
Connections per second: 135,000
Maximum security policies: 10,000
IPsec VPN throughput (Gbit/s): 9
IPsec VPN tunnels: 2,000
IPS throughput (Gbit/s): 6
Application Control throughput (Gbit/s): 3.5
11
Power Supply Unit (PSU)
12
AC PSU
Type: Built-in
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU
Type: RPS
Quantity: 1
Rated voltage range: 12 VDC
14
Compatible Expansion Cards
15

Not supported
