Fortinet FortiGate 300E Series Available to Quote:

FortiGate 300E

FortiGate 301E

Request a Quote
Description Specifications Additional materials

The FortiGate 300E Series delivers next-generation firewalls in a compact package for mid-sized and large enterprises with deployment options on campus or branch office.

FortiGate 300E gateways support extensive routing, switching, wireless controller capabilities, and scalable IPsec VPN capabilities to combine network and security functions.

FortiGate 300E gateways provide flexible SD-WAN deployment, threat protection and low latency using a security processor (SPU). They protect against encrypted and unencrypted malware, vulnerabilities and malicious websites, and they detect attacks using continuous analysis.

General All
Interfaces
1
FortiGate 300E:
  • 16-Port 1GbE (SFP);
  • 16-Port 1GbE (RJ45);
  • 2-Port MGMT/HA 1GbE (RJ45);
  • 1-Port console (RJ45);
  • 2-Port USB
FortiGate 301E:
  • 16-Port 1GbE (SFP);
  • 16-Port 1GbE (RJ45);
  • 2-Port MGMT/HA 1GbE (RJ45);
  • 1-Port console (RJ45);
  • 2-Port USB;
  • 2 x 480 GB SSD local storage
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
44.45 (1U) x 432 х 380 mm
(1.75 (1U) x 17.0 x 15.0 in)
4
Maximum Weight (kg)
FortiGate 300E: 7.3 kg (16.1 lbs)
FortiGate 301E: 7.6 kg (16.6 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
FortiGate 300E: 173
FortiGate 301E: 180
9
Performance
10
Firewall throughput (64 Byte) (Gbit/s): 30
Firewall throughput (Mp/s): 30
Maximum concurrent sessions: 4M
Connections per second: 300,000
Maximum security policies: 10,000
IPsec VPN throughput (Gbit/s): 20
IPsec VPN tunnels: 2,000
IPS throughput (Gbit/s): 11
Application control throughput (Gbit/s): 7
11
Power Supply Unit (PSU)
12
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU

Not supported

14
Compatible Expansion Cards
15

Not supported

16
