Fortinet FortiGate 50E Series Available to Quote:

FortiGate 50E; FortiWiFi 50E

FortiGate 51E; FortiWiFi 51E

FortiGate 52E

Request a Quote
Description Specifications Additional materials

FortiGate 50E Series Gateways provide comprehensive network security in a compact size for branch and mid-sized businesses.

Security Gateways support basic routing, switching, and scalable IPsec VPN capabilities to protect your data and applications.

The FortiGate 50E Series provides flexible SD-WAN deployment and robust cyber threat protection using the SPU security processor. Gateways also provide reliable protection against malware, websites, application control, and detect attacks through continuous analysis.

General All
Interfaces
1
FortiGate 50E:
  • 7-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN and 5-Port LAN;
  • 1-Port USB;
  • 1-Port console (RJ45)
FortiWiFi 50E
  • 7-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN and 5-Port LAN;
  • 1-Port USB;
  • 1-Port console (RJ45);
  • WiFi. IEEE 802.11 a/b/g/n (2.4GHz)
FortiGate 51E:
  • 7-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN and 5-Port LAN;
  • 1-Port USB;
  • 1-Port console (RJ45);
  • 32 GB local storage
FortiWiFi 51E:
  • 7-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN and 5-Port LAN;
  • 1-Port USB;
  • 1-Port console (RJ45);
  • WiFi. IEEE 802.11 a/b/g/n (2.4GHz);
  • 32 GB local storage
FortiGate 52E:
  • 7-Port 1GbE (RJ45) (Bundle includes: 2-Port WAN and 5-Port LAN;
  • 1-Port USB;
  • 1-Port console (RJ45);
  • 2 x 32 GB local storage
2
Физические параметры
3
Physical Parameters
36 x 216 х 140
(1.44 x 8.52 x 5.5 in)
4
Maximum Weight (kg)
FortiGate 50E:
0.914 (2.015 lbs)
FortiWiFi 50E:
0.926 (2.041 lbs)
FortiGate 51E:
FortiWiFi 51E:
FortiGate 52E:
0.925 (2.04 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

20 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)
Fortigate 50E: 18
FortiWiFi 50E: 22
Fortigate 51E: 20
FortiWiFi 51E: 23
Fortigate 52E: 27
9
Performance
10
Firewall throughput (Gbit/s): 2.5
Firewall throughput (Kp/s): 375
Maximum concurrent sessions: 1.8М
Connections per second: 21,000
Maximum security policies: 5000
IPsec VPN throughput (Mbit/s): 200
IPsec VPN tunnels: 250
IPS throughput (Mbit/s): 800
Application Control throughput (Mbit/s): 350
11
Power Supply Unit (PSU)
12
AC PSU
Type: External
Type: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz.



13
DC PSU

Not supported

14
Compatible Expansion Cards
15

Not supported

16
