Fortinet FortiGate 90E Series Available to Quote:

FortiGate 90E

FortiGate 91E

Request a Quote
Description Specifications Additional materials

The FortiGate 90E Series is the next generation of firewalls for mid-sized and large enterprises that provides extensive routing, switching, wireless controller capabilities and scalable IPsec VPN capabilities to combine network and security functions.

FortiGate 90E gateways provide flexible UTM and Secure SD-WAN deployments, better threat protection and ultra-low latency using dedicated Security Processor Technology (SPUs).

General All
Interfaces
1
FortiGate 90E:
  • 12-Port 1GbE (RJ45);
  • 2-Port DMZ/HA 1GbE (RJ45);
  • 2-Port 1GbE (RJ45) WAN;
  • 1-Port console (RJ45);
  • 1-Port USB
FortiGate 90E/91E:
  • 12-Port 1GbE (RJ45);
  • 2-Port DMZ/HA 1GbE (RJ45);
  • 2-Port 1GbE (RJ45) WAN;
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 128 GB SSD local storage
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
43.9 (1U) x 216 х 178.5 mm
(1.7 (1U) x 8.5 x 7.0 in)
4
Maximum Weight (kg)
FortiGate 90E: 1.30 kg (2.88 lbs)
FortiGate 91E: 1.32 kg (2.91 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
FortiGate 90E: 27.36
FortiGate 91E: 28.44
9
Performance
10
Firewall throughput (Gbit/s): 4.0
Firewall throughput (Kp/s): 375
Maximum concurrent sessions: 1.2M
Connections per second: 27,500
Maximum security policies: 5,000
IPsec VPN throughput (Gbit/s): 245
IPsec VPN tunnels: 2,500
IPS throughput (Gbit/s): 1.0
Application Control throughput (Mbit/s): 510
11
Power Supply Unit (PSU)
12
AC PSU
Type: External
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU

Not supported

14
Compatible Expansion Cards
15

Not supported
