Juniper SRX110 Series Available to Quote:

SRX110H2-VA

End-of-Sale: SRX110H2-VB

Request a Quote
Description Specifications Additional materials

The Juniper Networks SRX110 Series Service Gateway is a high-performance solution that includes security, routing, switching, and unified threat management (UTM).

The SRX110 provides content protection, application visibility, policy tracking and enforcement, role and user-based monitoring, and threat visibility and control throughout the network. Firewall in a compact 1U form factor with fixed 10 / 100MbE ports.

General All
Interfaces
1
SRX100H2-VA:
  • 1-Port VDSL/ADSL2+ (Annex A) WAN;
  • 8-Port 10/100MbE (RJ45) LAN;
  • 2-Port USB;
  • 1-Port console (RJ45)
SRX110H2-VB:
  • 1-Port VDSL/ADSL2+ (Annex B) WAN;
  • 8-Port 10/100MbE (RJ45) LAN;
  • 2-Port USB;
  • 1-Port console (RJ45)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
43.7 (1U) x 280 х 213
(1.72 (1U) x 11.02 x 8.39 in)
4
Maximum Weight (kg)

3.06 (6.75 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)

10

9
Performance
10
Firewall throughput IMIX (Mbit/s) 700
Firewall throughput (64 Byte) (Kp/s): 70
Maximum concurrent sessions: 32,000
Connections per second: 1800
Maximum security policies: 384
IPsec VPN throughput (Mbit/s): 65
IPsec VPN tunnels: 128
IPS throughput (Mbit/s): 75
Application Control throughput (Mbit/s): 25
11
Power Supply Unit (PSU)
12
AC PSU
Type: External
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU

Not supported

14
Compatible Expansion Cards
15

Not supported

16
