Juniper SRX210 Series

End-of-Sale

Please see "Similar Products" below.



Description Specifications Additional materials

Security Gateway for Small Enterprises

General All
Interfaces
1
SRX210HE2:
  • 2-Port 1GbE (RJ45) WAN;
  • 6-Port 10/100MbE (RJ45) LAN;
  • 1 Mini PIM card expansion slot;
  • 2-Port USB;
  • 1-Port console (RJ45)
SRX210HE2-POE:
  • 2-Port 1GbE (RJ45) WAN;
  • 6-Port 10/100MbE (RJ45) (including 4 ports with PoE support) (LAN);
  • 1 Mini PIM expansion card slot;
  • 2-Port USB;
  • 1-Port console (RJ45)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
44 (1U ) x 280 х 181
(1.73 (1U) x 11.02 x 7.13 in)
4
Maximum Weight (kg)
SRX210HE2: 1.5 (3.3 lbs)
SRX210HE2-POE: 2.0 (4.4 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
SRX210HE2: 28
SRX210HE2-POE: 84
9
Performance
10
Firewall throughput IMIX (Mbit/s): 850
Firewall throughput (64 Byte) (Kp/s): 95
Maximum concurrent sessions: 64,000
Connections per second: 2200
Maximum security policies: 512
IPsec VPN throughput (Mbit/s): 85
IPsec VPN tunnels: 256
IPS throughput (Mbit/s): 65
Application Control throughput (Mbit/s): 30
11
Power Supply Unit (PSU)
12
AC PSU
Type: External
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
13
DC PSU

Not supported

14
Compatible Expansion Cards
15
Compatible Mini-PIM Cards
Model Number Description
SRX-MP-1SERIAL: 1-Port serial (DCE/DTE)
SRX-MP-1ADSL2-A: 1-Port ADSL2+ (Annex A)
SRX-MP-1ADSL2-B: 1-Port ADSL2+ (Annex B)
SRX-MP-1VDSL2-A: 1-Port VDSL2
SRX-MP-8GSHDSL: 1-Port G.SHDSL (4 pairs)
SRX-MP-1SFP-GE: 1-Port SFP
SRX-MP-1T1E1: 1-Port E1
