GPON MDU Huawei SmartAX MA5616

Interfaces

MA5616:

4 Service Cards slots;
1 Control Card slot;
1 Power Card slot

Physical Parameters

Dimensions (HxWxD) (mm)

88.1 (2U) x 482.6 х 245

(3.47 (2U) x 19 x 9.65 in)

Maximum Weight (kg)

10.5 (23.15 lbs)

Environmental Conditions

Relative Humidity (%)

5 to 95

Operating Temperature (°C)

-40 to +65 (-40 to +149 °F)

Maximum Power Consumption (W)

300

Performance

Switching Bandwidth (Gbit/s)

MA5616 with CCUB control card:	10.4
MA5616 with CCUC control card:	20
MA5616 with CCUE control card:	28

Forwarding Rate (Mp/s)

MA5616 with CCUB control card:	15.6
MA5616 with CCUC control card:	30
MA5616 with CCUE control card:	51

MAC Address Table (entries)

MA5616 with CCUB control card:	4000
MA5616 with CCUC control card:	4000
MA5616 with CCUE control card:	16,000

ARP Table (entries)

1024

Layer 2 Features

VLAN

IEEE 802.1Q: 4000. GVRP; QinQ; VLAN Translation

Multicast

IGMP snooping:	v2/v3
IGMP groups:	1024
Multicast VLAN (MVR):	Supported
Multicast Routing:	Not supported

Layer 3 features

Routing Table (routes)

256

IP Routing

Static Routing

Security

Local AAA:	Supported
RADIUS, TACACS+:	Only RADIUS
DHCP Server:	Not supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; SNMP; OMCI

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	1
Rated voltage range:	90 to 264 VAC, 50-60 Hz

AC PSU with power backup

Type:	Removable
Quantity:	1
Rated voltage range:	AC power supply: 90 to 264 VAC Power backup: -43.2 to -52 V DC

DC PSU

Type:	Removable
Quantity:	1
Rated voltage range:	-38.4 to -72 VDC

Compatible Control Cards

Model Number	Description
H831CCUB:	Control Card for MA5616 1 uplink daughter card and 1 voice daughter card
H831CCUC:	Control Card for MA5616 1 uplink daughter card and 1 voice daughter card
H831CCUE:	Control Card for MA5616 1 uplink daughter card and 1 voice daughter card

Uplink Daughter Cards:

Model Number	Description
H831GP1A:	Compatible with CCUB control card 1-Port GPON and 1-Port SFP
H831GE1A:	Compatible with CCUB control card 2-Port GE (SFP)
H831UP2A:	Compatible with CCUC and CCUE control cards 2-Port adaptive SFP (GPON or GE).
H831UP2C:	Compatible with CCUC and CCUE control cards 2-Port adaptive SFP (GPON or GE). Supports stratum-3 clock synchronization.
H831UP2AA:	Compatible with CCUE control card 2-Port adaptive SFP (GPON or GE).
H831UP2CA:	Compatible with CCUE control card 2-Port adaptive SFP (GPON or GE). Supports stratum-3 clock synchronization.
H833XP1A:	Compatible with CCUE control card 1-Port 10G GPON

Voice Daughter Cards:

Model Number	Description
H836ASDC:	Compatible with CCUB, CCUC, CCUE control cards Supports up to 64 voice users.
H836ASDM:	Compatible with CCUB, CCUC, CCUE control cards Supports up to 104 voice users.
H836ASDF:	Compatible with CCUE control card Supports up to 254 voice users.

Compatible Power Supply Cards

Model Number	Description
H831PDIA:	One -48 VDC input, a maximum output power of 300 W
H832PDIA:	Two -48 VDC inputs, a maximum output power of 300 W
H832PDVA:	One -48 VDC input, a maximum output power of 400 W
H832PDVAA:	One -48 VDC input, a maximum output power of 400 W
H832PDNAA:	One -48 VDC input, a maximum output power of 400 W
H831PAVDA:	One 220 VAC or 110 VAC input, a maximum output power of 400 W. With one battery input for power backup
H831PAIA:	One 220 VAC or 110 VAC input, a maximum output power of 200 W
H831PAIC:	One 220 VAC or 110 VAC input, a maximum output power of 400 W
H831PAIB:	One 220 VAC or 110 VAC input, a maximum output power of 200 W. With one battery input for power backup

Compatible Service Cards

ADSL2+ Service Cards

Model Number	Description
H83AADLE:	32-channel ADSL2+ over POTS
H835ADLE:	32-channel ADSL2+ over POTS
H836ADLE:	32-channel ADSL2+ over POTS
H836ADPE:	64-channel ADSL2+ over POTS

VDSL2 Service Cards

Model Number	Description
H835VDGE:	16-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H835VDSH:	24-channel VDSL2 over POTS
H835VDTH:	24-channel VDSL2 over ISDN
H835VDSE:	24-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83BVDLE:	32-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83BVDLF:	32-channel VDSL2
H83BVCLE:	32-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83BVCLF:	32-channel VDSL2
H836VCLE:	32-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83BVDMM:	48-channel VDSL2
H83BVCMM:	48-channel VDSL2.
H83DVCMM:	48-channel VDSL2.
H83DSDMM:	48-channel SuperVector
H836VCPE:	64-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83DVCPE:	64-channel VDSL2 over POTS. With embedded splitter (600-ohm impedance)
H83DVCPD:	64-channel VDSL2

SHDSL Service Cards

Model Number	Description
H832SHLH:	16-channel SHDSL

Ethernet Service Cards

Model Number	Description
H831EIUD:	4-Port combo 1GbE (RJ45/SFP); 4-Port 100MbE (SFP)
H831EIUA:	16-Port 100MbE (RJ45)

Voice Service Cards

Model Number	Description
H838ASRB:	32-channel POTS
H837ASPB:	64-channel POTS
H838ASPB:	64-channel POTS
H839ASPB:	64-channel POTS
H832DSLD:	8-channel ISDN
H831EDTB:	8-Port G.SHDSL and 8-port E1

Combo Service Cards

Model Number	Description
H83BCVLC:	32-channel VDSL2 and POTS
H83BCVLE:	32-channel VDSL2 and POTS
H836CCME:	48-channel VDSL2 and POTS
H83DCCME:	48-channel VDSL2 and POTS
H835CALE:	32-channel ADSL2+ and POTS
