GPON ONT Huawei Echolife EG8242H
GPON ONT Huawei Echolife EG8242H

End-of-Sale

Please see "Similar Products" below.
Description Specifications Additional materials

GPON ONT Huawei Echolife EG8242H

General All
Interfaces
1
EG8242H:
  • 1-Port GPON (SC/APC);
  • 4-Port 1GbE (RJ45);
  • 2-Port POTS (RJ11);
  • 1-Port CATV;
  • 1-Port USB
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
32 x 160 х 220
(1.25 x 6.3 x 8.66 in)
4
Maximum Weight (kg)

0.5 (1.1 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)

14

9
Interfaces Parameters
10
GPON
Class: B+
Operating wavelengths: DS 1490 nm, US 1310 nm
Receiver sensitivity (dBm): -27
11
VoIP
Supported protocols: SIP
Voice codecs: G.711A/µ, G.729a/b, G.722
Fax: T.30 / T.38
12
CATV
Bandwidth (MHz): 54 to 870
Output resistance (Ohm): 75
13
Layer 2 Features
14
VLAN

VLAN filtering. VLAN transparent transmission

15
Multicast
16

IGMP snooping:  v1/v2/v3, IGMP Proxy, Dynamically controllable multicast

17
Security
18
MAC address filtering, IP address filtering, URL filtering;
NAT/NAPT, Port Forwarding, ALG, UPnP, DDNS/DNS server / DNS client
19
Power Supply Unit (PSU)
20
AC PSU
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 11 to 13 VDC. 2А
21
DC PSU

Not supported

22

EG8242H Datasheet (en)
