GPON ONT Huawei Echolife EG8245H

End-of-Sale

Please see "Similar Products" below.



Description Specifications Additional materials

GPON ONT Huawei Echolife EG8245H

General All
Interfaces
1
EG8245H:
  • 1-Port GPON (SC/UPC);
  • 4-Port 1GbE (RJ45);
  • 2-Port POTS (RJ11);
  • 1-Port USB;
  • Wi-Fi
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
28 x 176 х 138.5
(1.1 x 6.9 x 5.4 in)
4
Maximum Weight (kg)

1.0 (2.2 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)

15.5

9
Interfaces Parameters
10
GPON
Class: B+
Operating wavelengths: DS 1490 nm, US 1310 nm
Receiver sensitivity (dBm): -27
11
VoIP
Supported protocols: SIP / H.248
Voice codecs: G.711A/µ, G.729a/b, G.722
Fax: T.30 / T.38
12
WLAN
IEEE 802.11 b/g/n (2.4 G)
2 x 2 MIMO
Antenna gain: 5 dBi
WPS
13
Layer 2 Features
14
VLAN

VLAN filtering. VLAN transparent transmission

15
Multicast
16
IGMP snooping:  v1/v2/v3. IGMP Proxy;
Dynamically controllable multicast
17
Security
18
MAC addresses filtering, IP addresses filtering, URL filtering;
NAT/NAPT, Port Forwarding, ALG, UPnP, DDNS/DNS server / DNS client
19
Power Supply Unit (PSU)
20
AC PSU
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 11 to 14 VDC. 1.5А
21
DC PSU

Not supported



22
