GPON ONT Huawei Echolife EG8247H
GPON ONT Huawei Echolife EG8247H

End-of-Sale

Please see "Similar Products" below.
Description Specifications Additional materials

GPON ONT Huawei Echolife EG8247H

General All
Interfaces
1
EG8247H:
  • 1-Port GPON (SC/UPC);
  • 4-Port 1GbE (RJ45);
  • 2-Port POTS (RJ11);
  • 1-Port CATV;
  • 1-Port USB
  • Wi-Fi
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
32 x 220 х 160
(1.26 x 8.66 x 6.3 in)
4
Maximum Weight (kg)

1.0 (2.2 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)

18

9
Interfaces Parameters
10
GPON
Class: B+
Operating wavelengths: DS 1490 nm, US 1310 nm
Receiver sensitivity (dBm): -27
11
VoIP
Supported protocols: SIP
Voice codecs: G.711A/µ, G.729a/b, G.722
Fax: T.30 / T.38
12
CATV
Bandwidth (MHz): 54 to 870
Output resistance (Ohm): 75
13
WLAN
IEEE 802.11 b/g/n (2.4 GHz)
2 x 2 MIMO
Antenna gain: 5 dBi
WPS
14
Layer 2 Features
15
VLAN

VLAN filtering. VLAN transparent transmission

16
Multicast
17
IGMP snooping:  v1/v2/v3. IGMP Proxy;
Dynamically controllable multicast
18
Security
19
MAC address filtering, IP addresses filtering, URL filtering;
NAT/NAPT, Port Forwarding, ALG, UPnP, DDNS/DNS server / DNS client
20
Power Supply Unit (PSU)
21
AC PSU
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 11 to 14 VDC. 2А
22
DC PSU

Not supported



23

EG8247H Datasheet (en)
