GPON ONT Huawei Echolife HG8045Q
GPON ONT Huawei Echolife HG8045Q

End-of-Sale

Please see "Similar Products" below.
Description Specifications Additional materials

GPON ONT Huawei Echolife HG8045Q

General All
Interfaces
1
HG8045Q:
  • 1-Port GPON (SC/APC);
  • 4-Port 1GbE (RJ45);
  • 1-Port USB;
  • Wi-Fi
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
30 x 230 х 190
(1.1 x 9.05 x 7.48 in)
4
Maximum Weight (kg)

0.5 (1.1 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)

21

9
Interfaces Parameters
10
GPON
Class: B+
Operating wavelengths: DS 1490 nm, US 1310 nm
Receiver sensitivity (dBm): -27
11
WLAN
IEEE 802.11 b/g/n (2.4 ГГц);
IEEE 802.11 a/n/ac (5 ГГц)
3 x 3 MIMO
Antenna gain: 2 dBi
WPS
12
Layer 2 Features
13
VLAN

VLAN filtering. VLAN transparent transmission

14
Multicast
15
IGMP snooping:  v1/v2/v3. IGMP Proxy;
Dynamically controllable multicast
16
Security
17
MAC address filtering, IP address filtering, URL filtering;
NAT/NAPT, Port Forwarding, ALG, UPnP, DDNS/DNS server / DNS client
18
Power Supply Unit (PSU)
19
AC PSU
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 11 to 14 VDC.  2А
20
DC PSU

Not supported

21

HG8045Q Datasheet (en)
