OLT Huawei MA5608T

End-of-Sale

Please see "Similar Products" below.

Description Specifications Additional materials

Multifunctional OLT / MSAN for xPON / xDSL / VoIP Services

General All
Interfaces
1
MA5608T:
  • 2 Service Board slots;
  • 2 Control Board slots;
  • 1 Power Supply Card slot
2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
88.1 (2U) x 535 x 244.5
(3.47 (2U) x 21.06 x 9.63)
4
Maximum Weight (kg)/(lbs)

10 (22.05)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 85

7
Operating Temperature (°C)/(°F)

-5 to +45 (23 to 113)

8
Maximum Power Consumption (W)

195

9
Performance
10
Switching Bandwidth (Gbit/s)

720

11
MAC Address Table (entries)

32,000

12
ARP Table (entries)

8192

13
Maximum PON ports
14
Maximum GPON ports

32

15
Maximum XG-PON ports

16

16
Layer 2 Features
17
VLAN

IEEE 802.1Q: 4094.  GVRP; QinQ; VLAN Translation

18
Layer 2 Reliability

STP/RSTP/MSTP;  ERPS (G.8032)

19
Multicast
20
IGMP snooping: v2/v3
IGMP groups: 4096
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SSM
21
Layer 3 features
22
Routing Table (routes)

5120

23
IP Routing

Static Routing; RIPv1/2; OSPFv2; IS-IS; VRRP; BGP

24
MPLS / VPN
25
Supported by:
SCUN (with H801SPUB service board);
SCUH (with H801SPUB service board)
Supported Features:
MPLS:
MPLS-LDP; MPLS RSVP-TE; MPLS OAM; MPLS-TE
L3 VPN:
L3 interface-based VRF
L2 VPN:
VPLS; PWE3
26
Security
27
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server Not supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
28
Management
29

Telnet; SSH; LLDP; SNMP v1/v2/v3; Syslog; NTP

30
Compatible Control Boards
31
Model Number
Description
MCUD:
Control board for MA5608T
  • 4-Port 1GbE (SFP)
MCUD1:
Control board for МА5608Т
  • 2-Port 1GbE (SFP);
  • 2-Port 1/10GbE (SFP+)
32
Compatible Power Supply Cards
33
Model Number
Description
MPWC:
Power Supply Card for МА5608Т
  • 2 x -48 VDC inputs
MPWD:
Power Supply Card for МА5608Т
  • 1 x 220 VAC input;
  • 1 x -48 VDC battery backup port
MPWE:
Power Supply Card for МА5608Т
  • 1 x -48 VDC input
34
Compatible Service Boards
35
GPON Boards
Model Number
Description
GPBD:
  • 8-Port GPON. Maximum splitting ratio: 1:128
GPFD:
  • 16-Port GPON. Maximum splitting ratio: 1:128
GPBH:
  • 8-Port GPON. Maximum splitting ratio: 1:128
GPMD:
  • 8-Port GPON. Maximum splitting ratio: 1:128



36
XG-PON Boards
Model Number
Description
XGBC:
  • 4-Port XG-PON
XGBD:
  • 8-Port XG-PON
37
SPU Boards
Model Number
Description
SPUA:
Uplink board for Open Access scenario
  • 8-Port 1GbE (SFP);
  • 2-Port 10GbE (SFP+)
SPUB:
MPLS board
SPUC:
Uplink board for Open Access scenario
  • 20-Port 1GbE (CSFP);
  • 4-Port 10GbE (SFP+)
SPUF:
Uplink board for Open Access scenario.
  • Supports L2 and L3 transfer modes.
  • 8-Port 1/10GbE (SFP/SFP+)
38
Ethernet Service Boards
Model Number
Description
ETHB:
Ethernet service card
  • 8-Port 1GbE (SFP)
39
P2P Service Boards
Model Number
Description
OPFA:
P2P services board
  • 16-Port 100MbE (SFP)
OPGD:
P2P services board
  • 24-Port 100/1000MbE (SFP) or 48-Port 100/1000MbE (CFSP)
OPGE:
P2P services board
  • 24-Port 100/1000MbE (SFP) or 48-Port 100/1000MbE (CFSP).  Supports 1588v2 (PTP)
40
TDM Service Boards
Model Number
Description
CSPA:
CESoP service board.
  • Structure-agnostic TDM over packet (SAToP);
  • 64-Channel E1
TOPB:
TDM Traffic over PSN service board.
  • Supports the following features: Native TDM, CESoP, STM-1
  • 2-Port STM-1 (SFP)
TOPA:
TDM Traffic over PSN service board.
Supports the following features:
  • Native TDM (with NH1A/O2CE extension card);
  • CESoP (with EH1A/CSSA extension card);
  • TDM (with 16-Channel E1 (with NH1A/EH1A extension card);
  • TDM (with 2-Channel STM-1 (with O2CE/CSSA extension card);
41
Voice Service Boards
Model Number
Description
ASPB:
Voice Services board
  • 64-Port VoIP POTS
DSRE:
Voice Services board
  • 32-Channel ISDN
EDTB:
Voice Services board
  • 16-Port SHDSL;
  • 16-Port E1
42
ATM Service Boards
Model Number
Description
AIUG:
ATM services board
  • 4-Port STM-1 (SFP)
43
ADSL2+ Service Boards
Model Number
Description
ADPD:
ADSL over POTS service board
  • 64-Port ADSL2+
ADPM:
ADSL over POTS service board.
  • 64-Port  ADSL2+. Supports MELT
ADQD:
ADSL over ISDN service board
  • 64-Port ADSL2+
ADKM:
ADSL over ISDN service board
  • 64-Port ADSL2+. Supports ADSL Bonding
ADPE:
ADSL over POTS service board
  • 64-Port ADSL2+. Internal 600ohms splitter
44
VDSL Service Boards
Model Number
Description
VDRD:
VDSL2 over POTS service board
  • 24-Port VDSL2
VDMF:
VDSL2 over POTS service board
  • 48-Port VDSL2. Supports VDSL2 PTM Bonding
VDNF:
VDSL2 over ISDN service board
  • 48-Port VDSL2
VDJM:
VDSL2 over ISDN service board
  • 48-Port VDSL2. Supports G.INP
VDPD:
VDSL2 over POTS service board
  • 64-Port VDSL2. Supports VDSL2 PTM Bonding
VDPE:
VDSL2 over POTS service board
  • 64-Port VDSL2
VDPM:
VDSL2 over POTS service board
  • 64-Port VDSL2. Supports MELT
VDQM:
VDSL2 over ISDN service board.
  • 64-Port VDSL2
VCMM:
VDSL2 over POTS service board
  • 48-Port VDSL2. Supports MELT supported. Support sVDSL2 PTM Bonding
VCPE:
VDSL2 over POTS service board
  • 64-Port VDSL2. Supports VDSL2 PTM Bonding. Internal splitter
VCPD:
VDSL2 over POTS service board
  • 64-Port VDSL2. Supports VDSL2 PTM Bonding
VCPM:
VDSL2 over POTS service board
  • 64-Port VDSL2. Supports MELT. Supports VDSL2 PTM Bonding
45
Vectoring Service Boards
Model Number
Description
VPEA:
VDSL Vectoring feature board. Compatible with the following VDSL2 Cards: VCMM, CCPE, VCPD, VCPE, VCPM
VPGA:
VDSL Vectoring feature support. Compatible with the following VDSL2 Cards: VCMM, CCPE. VCPD, VCPE, VCPM
46
Combo Service Boards
Model Number
Description
CAME:
ADSL over POTS service board
  • 48-Port ADSL2+ and POTS with built-in splitter
CVME:
VDSL over POTS service board
  • 48-Port VDSL2 and POTS with built-in splitter
CCPE:
VDSL over POTS service board
  • 64-Port VDSL2 and POTS with built-in splitter
47
SHDSL Service Boards
Model Number
Description
SHLM:
SHDSL.bis service board
  • 16-Port SHDSL
SHGM:
SHDSL.bis service board
  • 32-Port SHDSL
48
SHDSL Extension Boards
Model Number
Description
SHET:
64-Channel SHDSL extension board.
  • Compatible with the folowing service boards: SHLM, SHGM
49
ADSL Splitter Boards
Model Number
Description
SPPLA:
Splitter board. Complex impedance (ETSI TS 101 952 01 01 option A).
  • Compatible with the folowing service board: ADPD
SPPLB:
Splitter board. BT complex impedance.
  • Compatible with the folowing service board: ADPD
SPPLC:
Splitter board. Complex impedance (ETSI TS 101 952 01 01 option B).
  • Compatible with the folowing service board: ADPD
SPPH:
Splitter board. 2B1Q or 4B3T.
  • Compatible with the folowing service board: ADQD
SPPF1:
Splitter board. 600 Ohm.
  • Compatible with the folowing service board: ADPD
50
VDSL Splitter Boards
Model Number
Description
VSNF:
Splitter board. 600ohms.
  • Compatible with the folowing service boards: VDMF, VDRD
VSNLA:
Splitter board. Complex impedance (ETSI TS 101 952 01 01 option A).
  • Compatible with the folowing service boards: VDMF, VDRD
VSPHA:
Splitter board. 2B1Q or 4B3T.
  • Compatible with the folowing service boards: VDNF, VDJM
VSPLA:
Splitter board. Complex impedance (ETSI TS 101 952 01 01 option A).
  • Compatible with the folowing service boards: VDPM, VDQM, VDPD
VSPLC:
Splitter board. Complex impedance (ETSI TS 101 952 01 01 option B).
  • Compatible with the folowing service boards: VDPM, VDQM, VDPD
51
