OLT Huawei MA5800 Series
OLT Huawei MA5800 Series Available to Quote:

MA5800-X17; MA5800-X15

MA5800-X7; MA5800-X2

 Request a Quote
Description Specifications Additional materials

Powerful OLT Series for GPON / XG-PON Services

General All
Interfaces
1
MA5800-X17 (ETSI):
  • 17 Service Boards slots;
  • 2 Control Boards slots;
  • 2 DC Power Supply Card slots
MA5800-X15 (IEC):
  • 15 Service Boards slots;
  • 2 Control Boards slots;
  • 2 DC Power Supply Card slots
MA5800-X7:
  • 7 Service Boards slots;
  • 2 Control Boards slots;
  • 2 DC Power Supply Card slots
MA5800-X2:
  • 2 Service Boards slots;
  • 2 Control Boards slots;
  • 1 Power Supply Card slot (AC / DC inputs)



2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
MA5800-X17 (including mounting brackets):
486 (11U) x 535 x 268.7
(19.1 (11U) x 21.06 x 10.58)
MA5800-X15 (including mounting brackets):
486 (11U) x 482.6 x 268.7
(19.1 (11U) x 19.0 x 10.58)
MA5800-X7 (including mounting brackets):
263.9 (6U) x 482.6 x 268.7
(10.4 (6U) x 19.0 x 10.58)
MA5800-X2  (including mounting brackets):
88.1 (2U) x 482.6 x 268.7
(3.47 (2U) x 19.0 x 10.58)



4
Maximum Weight (kg)/(lbs)
MA5800-X17: 45 (99.2)
MA5800-X15: 33 (75.7)
MA5800-X7: 26 (57.3)
MA5800-X2: 9.4 (20.7)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 85

7
Operating Temperature (°C)/(°F)

-40 to +65 (-40 to 149)

8
Maximum Power Consumption (W)
MA5800-X17: 1256
MA5800-X15: 1156
MA5800-X7: 662
MA5800-X2: 299.5
9
Performance
10
Switching Bandwidth (Gbit/s)
MA5800-X17:
MA5800-X15:
MA5800-X7:
  7000
MA5800-X2  480
11
MAC Address Table (entries)

262,143

12
ARP Table (entries)

65,536

13
Maximum PON ports
14
Maximum GPON ports
MA5800-X17: 272
MA5800-X15: 240
MA5800-X7: 117
MA5800-X2 32
15
Maximum XG-PON ports
MA5800-X17: 136
MA5800-X15: 120
MA5800-X7: 56
MA5800-X2 16
16
Layer 2 Features
17
VLAN

IEEE 802.1Q: 4094; QinQ; VLAN Translation

18
Layer 2 Reliability

STP/RSTP/MSTP;  ERPS (G.8032)

19
Multicast
20
IGMP snooping: v2/v3
IGMP groups: 8192
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SSM
21
Layer 3 features
22
Routing Table (routes)
IPv4: 65,536
IPv6: 16,384
23
IP Routing

Static Routing; RIPv1/2; OSPFv2; IS-IS; BGP

24
MPLS / VPN
25

Supported. MPLS LDP, VPLS, PWE3

26
Security
27
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Not supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
28
Management
29

Telnet; SSH; LLDP; SNMP v1/v2/v3; Syslog; NTP

30
Compatible Control Boards
31
Model Number Description
MPLA:

Control Board for MA5800-X17/X15/X7

  • 4-Port 1/10GbE (SFP/SFP+)
MPLB:

Control Board for MA5800-X17/X15/X7

  • 4-Port 1/10GbE (SFP/SFP+)
MPSC:

Control Board for MA5800-X2

  • 4-Port 1/10GbE (SFP/SFP+)
32
Compatible Power Supply Cards
33
Model Number Description
PILA:

Power supply card for MA5800-X17/X15/X7

  • 1 x -48 VDC input
PISA:

Power supply card for MA5800-X2

  • 2 x -48 VDC inputs
PISB:

Power supply card for MA5800-X2

  • 1 x 220 VAC input;
  • 1 x -48 VDC battery backup port
34
Compatible Uplink Boards
35
Model Number Description
NXED:

Uplink Board for MA5800-X17/X15/X7

  • (8-Port 1/10GbE (SFP/SFP+)
36
Compatible Universal Interface Boards
37
Model Number Description
CIUA:

BITS Board for MA5800-X17/X15/X7

  • 2-Port BITS clock input;
  • 1-Port  BITS clock output (2 MHz / 2 Mbit/s);
  • 2-Port 1PPS + TOD
38
Compatible Service Boards
39
GPON Boards
Model Number Description
GPHF:

GPON Board for MA5800-X17/X15/X7/X2

  • 16-Port GPON. Maximum splitting ratio: 1:128
GPSF:

GPON Board for MA5800-X17/X15/X7/X2

  • 16-Port GPON. MAximum splitting ratio: 1:128



40
XG-PON Boards
Model Number Description
XGHD:

XG-PON Board for MA5800-X17/X15/X7/X2

  • 8-Port XG-PON. Splitting ratio: 1:256
XSED:

XG-PON Board for MA5800-X17/X15/X7/X2

  • 8-Port XG-PON. Splitting ratio: 1:256
TWED:

XG-PON Board for MA5800-X17/X15/X7/X2

  • 8-Port XG-PON. Splitting ratio: 1:256
CGCD:

 XG-PON Board for MA5800-X17/X15/X7/X2

  • 8-Port GPON / XG-PON. Maximum splitting ratio: 1:128 (GPON), 1:256 (XG-PON)
41
Ethernet Service Boards
Model Number Description
OXHD:

Ethernet service Board for MA5800-X17/X15/X7/X2

  • 8-Port 1G/10GbE (SFP/SFP+)
42
TDM Service Boards
Model Number Description
EDSH:

TDM E1 Board for MA5800-X17/X15/X7/X2

  • 2 x 16-Channel E1 interfaces (NE96 connector)
43
P2P Service Boards
Model Number Description
OGHK:

P2P services Board for MA5800-X17/X15/X7/X2

  • 24-Port 100/1000MbE (SFP) or 48-Port 100/1000MbE (CFSP)
44
Video Service Boards
Model Number Description
CVEC:

Video service processing board. Operates together with the downstream media converter (CMC), processes DVB services.

  • 256 input transport streams (TS)
45
