Router Huawei AR3200 Series

Router Huawei AR3200 Series Available to Quote:

AR3260

Request a Quote

Description Specifications Additional materials

The Huawei AR3200 Router has a high bandwidth of up to 640 Gb/s, providing flexible routing and switching.

The Huawei AR3200 Router allows customers to select 2 control boards and up to 9 interface boards, which provide a wide variety of interfaces.

The Huawei AR3200 Router has 4 SIC slots, 2 WSIC slots, 4 XSIC slots, and 2 SRU control card slots.

General All

Interfaces

AR3260:

4 Expansion slots SIC on the rear panel;
2 Expansion slots WSIC on the rear panel;
4 Expansion slots XSIC on the rear panel;
2 Control Card (SRU) slots on the front panel

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

130.5 (3U) x 482.6 x 470

(5.14 (3U) x 19.0 x 18.5)

Maximum Weight (kg)/(lbs)

11 (24.25)

Environmental Conditions

Relative Humidity (%)

5 to 90

Operating Temperature (°C)/(°F)

0 to 45 (32 to 113)

Maximum power consumption (W)

850

Acoustic noise (dB)

WLAN

Not supported

AP Management Feature

Maximum AP Supported:
SRU40:	16 (with AC License)
SRU80: SRU100: SRU100E:	32 (with AC License)
SRU200: SRU200E:	64 (with AC License)
SRU400:	128 (with AC License)
Compatible AP:	AP6010SN-GN; AP6010DN-AGN; AP6310SN-GN; AP6510DN-AGN; AP6610DN-AGN; AP7110SN-GN; AP7110DN-AGN; AP5010SN-GN; AP5010DN-AGN; AP3010DN-AGN; AP6510DN-AGN-US; AP6610DN-AGN-US; AP5030DN; AP5130DN; AP7030DE; AP2010DN; AP8130DN; AP8030DN; AP9330DN; AP4030DN; AP4130DN; AP3030DN; AP2030DN; AP9131DN; AP3010DN-V2

Performance

Switching Bandwidth (Gbit/s)

640

Forwarding rate (Mp/s)

SRU40:	3000
SRU80: SRU100:	5000
SRU100E:	5500
SRU200E:	7000
SRU200:	20,000
SRU400:	24,000

MAC Address Table (entries)

SRU40:	4096
SRU80: SRU100: SRU100E: SRU200: SRU200E: SRU400:	8192

ARP Table (entries)

SRU40:	4000
SRU80: SRU200: SRU200E:	10,000
SRU100: SRU100E:	6000
SRU400:	16,000

Layer 2 Features

VLAN

IEEE 802.1Q:

4094

Layer 3 features

Routing Table (prefixes)

Routing Table (RIB):
SRU40:	300,000
SRU80: SRU100: SRU100E:	500,000
SRU200: SRU200E:	800,000
SRU400:	1M
Forwarding Table (FIB):
SRU40:	300,000
SRU80: SRU100: SRU100E:	500,000
SRU200: SRU200E:	800,000
SRU400:	1M

IP Routing

Static Routing; BGP; IS-IS; OSPFv2

MPLS / VPN

MPLS LDP; GRE; L3VPN; L2VPN

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
BRAS:	Supported
NAT:	Supported
Packet Filtering:	Supported

Management

Telnet; SNMP v1/v2/v3; SSH; NETCONF; Web

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-40 to -72 VDC

PoE (Power over Ethernet)

PoE (802.3af) (15W per port):	56 ports
PoE+ (802.3аt) (30W per port):	28 ports
PoE++ (802.3bt) (60W per port):	Not supported
PoE++ (802.3bt) (90W per port):	Not supported

Compatible Control Cards (SRU)

Model Number	Description
SRU40:	Control card for AR3260 CPU: 8-core, 600 MHz , Memory: 2 GB, Flash: 16 MB
SRU80:	Control card for AR3260 CPU: 12-core, 750 MHz , Memory: 2 GB, Flash: 16 MB
SRU100E:	Control card for AR3260 CPU: 12-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU200:	Control card for AR3260 CPU: 32-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU200E:	Control card for AR3260 CPU: 12-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU400:	Control card for AR3260 CPU: 32-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB

Compatible Expansion Cards SIC

SIC Ethernet cards

Model Number	Description
4ES2G-S:	Ethernet LAN card for AR3260 4-Port 1GbE (RJ45)
4ES2GP-S:	Ethernet LAN card for AR3260 4-Port 1GbE (RJ45) PoE
1GEC:	Ethernet WAN card for AR3260 1-Port combo 1GbE (RJ45/SFP)
2FE:	Ethernet WAN card for AR3260 2-Port 100MbE (RJ45)

SIC E1/T1 cards

Model Number	Description
1E1/T1-M:	E1/T1 card for AR3260 1-Port CE1/CT1/PRI/VE1 (DB9)
2E1/T1-M:	E1/T1 card for AR3260 2-Port CE1/CT1/PRI/VE1 (DB9)
1E1/T1-F:	E1/T1 card for AR3260 1-Port E1/T1-F (DB9)
2E1/T1-F:	E1/T1 card for AR3260 2-Port E1/T1-F (DB9)

SIC Sync WAN cards

Model Number	Description
1SA:	Sync WAN card for AR3260 1-Port SA (DB28)
2SA:	Sync WAN card for AR3260 2-Port SA (DB28)

SIC 3G/LTE cards

Model Number	Description
3G-HSPA+7:	3G card for AR3260 2 x 3G antennas (SMA); 1-Port miniUSB
3G-EVDO:	EVDO card for AR3260 2 x 3G antennas (SMA); 1-Port miniUSB
1LTE-L:	LTE card for AR3260 2 x LTE antennas (SMA); 1-Port miniUSB
1LTE-LV:	LTE card for AR3260 2 x LTE antennas (SMA); 1-Port miniUSB
1LTEC:	LTE card for AR3260 2 x LTE antennas (SMA); 1-Port miniUSB
1LTE-Lt:	LTE card for AR3260 2 x LTE antennas (SMA)
1LTE-Lt-7:	LTE card for AR3260 2 x LTE antennas (SMA)
1LTE-Lo:	LTE card for AR3260 2 x LTE antennas (SMA)
1LTE-Lc:	LTE card for AR3260 2 x LTE antennas (SMA)

SIC POS/CPOS cards

Model Number	Description
1CPOS-155M:	CPOS card for AR3260 1-Port CPOS 155 Mbit/s (SFP)

SIC ISDN cards

Model Number	Description
1BST:	ISDN card for AR3260 1-Port ISDN S/T (RJ45)
2BST:	ISDN card for AR3260 2-Port ISDN S/T (RJ45)

SIC Voice cards

Model Number	Description
4FXS1FXO:	Voice card for AR3260 4-Port FXS (RJ11); 1-Port FXO (RJ11)
4FXO:	Voice card for AR3260 4-Port FXO (RJ11)
1VE1:	Voice card for AR3260 4-Port VE1 (DB9)

SIC xDSL cards

Model Number	Description
1ADSL-A/M:	ADSL2+ WAN card for AR3260 1-Port ADSL-A/M (RJ11)
1ADSL-B/J:	ADSL2+ WAN card for AR3260 1-Port 1ADSL-B/J (RJ11)
4G.SHDSL:	G.SHDSL WAN card for AR3260 1-Port G.SHDSL (RJ45)
VDSL2:	VDSL2 WAN card for AR3260 1-Port VDSL2 (RJ11)
2VDSL2:	VDSL2 WAN card for AR3260 1-Port VDSL2 (RJ11)

SIC xPON cards

Model Number	Description
1PON:	xPON WAN card for AR3260 1-Port GPON/EPON (SFP)

SIC Capacitor cards

Model Number	Description
DGP:	Dying Gasp Capacitor Card for AR3260 (SRU80 / SRU100E / SRU200) Power supply time: >100 ms

Compatible Expansion Cards WSIC

WSIC Ethernet cards

Model Number	Description
8FE1GE:	Ethernet LAN card for AR3260 8-Port 100MbE (RJ45); 1-Port 1GbE (RJ45)
9ES2:	Ethernet LAN card for AR3260 8-Port 100MbE (RJ45); 1-Port 1GbE (RJ45)
4GE-2S:	Ethernet LAN card for AR3260 4-Port 1GbE (SFP)
4GECS:	Ethernet LAN card for AR3260 4-Port combo 1GbE (RJ45/SFP)
2FE:	Ethernet LAN card for AR3260 4-Port 100MbE (RJ45)
2X10GL:	Ethernet LAN card for AR3260 4-Port 10GbE (SFP+)
4GEW-T:	Ethernet WAN card for AR3260 4-Port 1GbE (RJ45)
4GEW-S:	Ethernet WAN card for AR326 4-Port 1GbE (SFP)

WSIC E1/T1 cards

Model Number	Description
2E1/T1-M-W:	E1/T1 card for AR3260 2-Port CE1/CT1/PRI/VE1 (DB9)
4E1/T1-M:	E1/T1 card for AR3260 4-Port CE1/PRI (RJ48)
8E1/T1-M:	E1/T1 card for AR3260 8-Port CE1/PRI (RJ48)
4E1/T1-F:	E1/T1 card for AR3260 4-Port E1-F (RJ48)
8E1/T1-F:	E1/T1 card for AR3260 8-Port E1-F (RJ48)
4E1-IMA:	E1/T1 card for AR3260 4-Port E1-IMA (RJ48)

WSIC E3/T3 cards

Model Number	Description
1E3/CE3/T3/CT3:	E3/T3 card for AR3260 1-Port E3 (SMB)

WSIC E&M cards

Model Number	Description
6E&M:	E&M card for AR3260 6-Port E&M (RJ45)

WSIC POS/CPOS cards

Model Number	Description
1CPOS-155M-W:	CPOS card for AR3260 1-Port CPOS 155 Mbit/s (SFP)
1STM1:	STM-1 card for AR3260 1-Port STM-1 155 Mbit/s (SFP)
1STM4:	STM-4 card for AR3260 1-Port STM-4 622 Mbit/s (SFP)
4STM1:	STM-1 card for AR3260 4-Port STM-1 155 Mbit/s (SFP)

WSIC Sync WAN cards

Model Number	Description
8SA:	Sync WAN card for AR3260 8-Port SA (DB28)
8AS:	Sync WAN card for AR3260 8-Port Async serial interfaces (RJ45)

WSIC ISDN cards

Model Number	Description
2BST-W:	ISDN card for AR3260 2-Port ISDN S/T (RJ45)

WSIC Voice cards

Model Number	Description
16FXS:	Voice card for AR3260 16-Port FXS (DB68)
32FXS:	Voice card for AR3260 32-Port FXS (DB68)

WSIC xDSL cards

Model Number	Description
1GBIS4W:	G.SHDSL WAN card for AR3260 1-Port G.SHDSL (RJ45)

Compatible Expansion Cards XSIC

XSIC Ethernet cards

Model Number	Description
24GE:	Ethernet LAN card for AR3260 24-Port 1GbE (RJ45)
24ES2GP:	Ethernet LAN card for AR3260 24-Port 1GbE (RJ45) PoE
