Router Huawei AR3600 Series

Router Huawei AR3600 Series Available to Quote:

AR3670

Request a Quote

Description Specifications Additional materials

The high-performance Huawei AR3600 Series Edge Router has throughput up to 640 Gb/s, and is perfect for branch offices and small businesses.

The AR3600 router provides flexible routing and switching for enterprises.

The AR3600 has 2 slots for SIC interface cards, 7 slots for WSIC interface cards, and 2 slots for SRU control cards.

2 SIC slots can be combined into one WSIC slot, and 2 WSIC slots can be combined into one XSIC slot.

General All

Interfaces

AR3670:

2 Expansion slots SIC on the rear panel;
7 Expansion slots WSIC on the rear panel;
2 Control Card (SRU) slots on the front panel;

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

130.5 (3U) x 482.6 x 470

(5.14 (3U) x 19.0 x 18.5)

Maximum Weight (kg)/(lbs)

11 (24.25)

Environmental Conditions

Relative Humidity (%)

5 to 90

Operating Temperature (°C)/(°F)

0 to 45 (32 to 113)

Maximum power consumption (W)

850

Acoustic noise (dB)

Performance

Switching Bandwidth (Gbit/s)

640

MAC Address Table (entries)

8192

ARP Table (entries)

10,000

WLAN

Not supported

AP Management Feature

Maximum AP Supported:	64 (with AC License)
Compatible AP:	AP6010SN-GN; AP6010DN-AGN; AP6310SN-GN; AP6510DN-AGN; AP6610DN-AGN; AP7110SN-GN; AP7110DN-AGN; AP5010SN-GN; AP5010DN-AGN; AP3010DN-AGN; AP6510DN-AGN-US; AP6610DN-AGN-US; AP5030DN; AP5130DN; AP7030DE; AP2010DN; AP8130DN; AP8030DN; AP9330DN; AP4030DN; AP4130DN; AP3030DN; AP2030DN; AP9131DN; AP3010DN-V2

Layer 2 Features

VLAN

IEEE 802.1Q:

4094

Layer 3 features

Routing Table (prefixes)

Routing Table (RIB):	800,000
Forwarding Table (FIB):	800,000

IP Routing

Static Routing; BGP; IS-IS; OSPFv2

MPLS / VPN

MPLS LDP; GRE; L3VPN; L2VPN

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
BRAS:	Supported
NAT:	Supported
Packet Filtering:	Supported

Management

Telnet; SNMP v1/v2/v3; SSH; NETCONF; Web

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-40 to -72 VDC

PoE (Power over Ethernet)

PoE (802.3af) (15W per port):	56 ports
PoE+ (802.3аt) (30W per port)	28 ports
PoE++ (802.3bt) (60W per port):	Not supported
PoE++ (802.3bt) (90W per port)	Not supported

Compatible Control Cards (SRU)

Model Number	Description
SRUX5:	Control Card for AR3670. CPU: 6-core, 2.2 GHz , Memory: 8 GB, Storage: flash 8 MB; HDD

Compatible Expansion Cards SIC

SIC Ethernet cards

Model Number	Description
1GEC:	Ethernet WAN card for AR3670 1-Port combo 1GbE (RJ45/SFP)
2FE:	Ethernet WAN card for AR3670 2-Port 100MbE (RJ45)

SIC E1/T1 cards

Model Number	Description
1E1/T1-M:	E1/T1 card for AR3670 1-Port CE1/CT1/PRI/VE1 (DB9)
2E1/T1-M:	E1/T1 card for AR3670 2-Port CE1/CT1/PRI/VE1 (DB9)
1E1/T1-F:	E1/T1 card for AR3670 1-Port E1/T1-F (DB9)
2E1/T1-F:	E1/T1 card for AR3670 2-Port E1/T1-F (DB9)

SIC Sync WAN cards

Model Number	Description
1SA:	Sync WAN card for AR3670 1-Port SA (DB28)
2SA:	Sync WAN card for AR3670 2-Port SA (DB28)

SIC 3G/LTE cards

Model Number	Description
3G-HSPA+7:	3G card for AR3670 2 x 3G antennas (SMA); 1-Port miniUSB
3G-EVDO:	EVDO card for AR3670 2 x 3G antennas (SMA); 1-Port miniUSB
1LTE-L:	LTE card for AR3670 2 x LTE antennas (SMA); 1-Port miniUSB
1LTE-LV:	LTE card for AR3670 2 x LTE antennas (SMA); 1-Port miniUSB
1LTEC:	LTE card for AR3670 2 x LTE antennas (SMA); 1-Port miniUSB
1LTE-Lt:	LTE card for AR3670 2 x LTE antennas (SMA)
1LTE-Lt-7:	LTE card for AR3670 2 x LTE antennas (SMA)
1LTE-Lo:	LTE card for AR3670 2 x LTE antennas (SMA)
1LTE-Lc:	LTE card for AR3670 2 x LTE antennas (SMA)

SIC POS/CPOS cards

Model Number	Description
1CPOS-155M:	CPOS card for AR3670 1-Port CPOS 155 Mbit/s (SFP))

SIC ISDN cards

Model Number	Description
1BST:	ISDN card for AR3670 1-Port ISDN S/T (RJ45))

SIC xDSL cards

Model Number	Description
1ADSL-A/M:	ADSL2+ WAN card for AR3670 1-Port ADSL-A/M (RJ11)
1ADSL-B/J:	ADSL2+ WAN card for AR3670 1-Port 1ADSL-B/J (RJ11)
4G.SHDSL:	G.SHDSL WAN card for AR3670 1-Port G.SHDSL (RJ45)
VDSL2:	VDSL2 WAN card for AR3670 1-Port VDSL2 (RJ11)
2VDSL2:	VDSL2 WAN card for AR3670 1-Port VDSL2 (RJ11)

SIC xPON cards

Model Number	Description
1PON:	xPON WAN card for AR3670 1-Port GPON/EPON (SFP)

Compatible Expansion Cards WSIC

WSIC Ethernet cards

Model Number	Description
8FE1GE:	Ethernet LAN card for AR3670 8-Port 100MbE (RJ45); 1-Port 1GbE (RJ45)
4GECS:	Ethernet LAN card for AR3670 4-Port combo 1GbE (RJ45/SFP))
2FE:	Ethernet LAN card for AR3670 4-Port 100MbE (RJ45)
2X10GL:	Ethernet LAN card for AR3670 4-Port 10GbE (SFP+)
4GEW-T:	Ethernet LAN card for AR3670 4-Port 1GbE (RJ45)
4GEW-S:	Ethernet LAN card for AR3670 4-Port 1GbE (SFP)

WSIC E1/T1 cards

Model Number	Description
2E1/T1-M-W:	E1/T1 card for AR3670 2-Port CE1/CT1/PRI/VE1 (DB9)
4E1/T1-M:	E1/T1 card for AR3670 4-Port CE1/PRI (RJ48)
8E1/T1-M:	E1/T1 card for AR3670 8-Port CE1/PRI (RJ48)
4E1/T1-F:	E1/T1 card for AR3670 4-Port E1-F (RJ48)
8E1/T1-F:	E1/T1 card for AR3670 8-Port E1-F (RJ48)
4E1-IMA:	E1/T1 card for AR3670 4-Port E1-IMA (RJ48)

WSIC E3/T3 cards

Model Number	Description
1E3/CE3/T3/CT3:	E3/T3 card for AR3670 1-Port E3 (SMB)

WSIC POS/CPOS cards

Model Number	Description
1CPOS-155M-W:	CPOS card for AR3670 1-Port CPOS 155 Mbit/s (SFP)
1STM1:	STM-1 card for AR3670 1-Port STM-1 155 Mbit/s (SFP)
1STM4:	STM-4 card for AR3670 1-Port STM-4 622 Mbit/s (SFP)
4STM1:	STM-1 card for AR3670 4-Port STM-1 155 Mbit/s (SFP)

WSIC Sync WAN cards

Model Number	Description
8SA:	Sync WAN card for AR3670 8-Port SA (DB28)
8AS:	Sync WAN card for AR3670 8-Port Async serial interfaces (RJ45)

WSIC ISDN cards

Model Number	Description
2BST-W:	ISDN card for AR3670 2-Port ISDN S/T (RJ45)

WSIC xDSL cards

Model Number	Description
1GBIS4W:	G.SHDSL WAN card for AR3670 1-Port G.SHDSL (RJ45)

Compatible Expansion Cards XSIC

XSIC Ethernet cards

Model Number	Description
24GE:	Ethernet LAN card for AR3670 24-Port 1GbE (RJ45)
24ES2GP:	Ethernet LAN card for AR3670 24-Port 1GbE (RJ45) PoE

AR3600 Datasheet (en)
