MX10003
Request a QuoteJuniper Networks MX10003 is a router with ports of 10GbE, 40GbE, 100GbE, provides a network with high bandwidth of up to 2.4 Tbps.
MX10003 provides a wide range of services for Metro Ethernet network, suitable for ISPs and mobile operators.
The router runs on JunOS operating system and Trio chipset, supports automation and rich routing features.
The MX10003 supports up to 72 x 10GbE ports, 18 x 40 GbE ports, and 12 x 100 GbE ports.
| MX10003: |
|
54.43 (120 lbs)
5 to 90
0 to 40 (32 to 104 °F)
2400
60
2.4
| Routing Table (RIB): | 20M |
| Forwarding Table (FIB): | 4M |
Static Routing; BGP; IS-IS; OSPFv2
LDP; RSVP; VPLS; L2VPN
| Local AAA: | Supported |
| RADIUS, TACACS+: | Supported |
| DHCP Server: | Not supported |
| BRAS: | Not supported |
| NAT: | Not supported |
| Packet Filtering: | Supported |
Telnet; SNMP v1/v2/v3; SSH; NETCONF
| Type: | Removable |
| Quantity: | 6 |
| Rated voltage range: | 90 to 264 VAC, 50-60 Hz |
| Type: | Removable |
| Quantity: | 6 |
| Rated voltage range: | -40 to -72 VDC |
|
Model Number
|
Description
|
|
JNP10003-RE1:
|
Routing and Control Board for MX10003.
CPU: 1.6 GHz , Memory: 64 GB, Storage: 100 GB SSD
|
|
Model Number
|
Description
|
|
JNP10003-LC2103:
|
6-Port 40GbE (QSFP+), 1 MIC slot
|
|
Model Number |
Description |
| JNP-MIC1: | 12-Port 100GbE (QSFP28) |
