Router Juniper MX150

Router Juniper MX150 Available to Quote:

MX150

Request a Quote

Description Specifications Additional materials

The Juniper MX150 is a compact border router with fixed 1GbE, 10GbE ports and bandwidth up to 20Gb/s.

General All

Interfaces

MX150:

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

43.7 (1U) x 440.9 х 304.8

(1.72 (1U) x 17.36 x 12.0)

Maximum Weight (kg)/(lbs)

4.3 (9.48)

Environmental Conditions

Relative Humidity (%)

5 to 90

Operating Temperature (°C)/(°F)

0 to 50 (32 to 122)

Maximum power consumption (W)

140

Acoustic noise (dB)

Performance

Switching Bandwidth (Gbit/s)

Layer 3 features

Routing Table (prefixes)

Routing Table (RIB):	20M (with S-MX150-R license)
Forwarding Table (FIB):	4M (with S-MX150-R license)

IP Routing

Static Routing; BGP (with S-MX150-IR/-R license); IS-IS (with S-MX150-IR/-R license); OSPFv2 (with S-MX150-IR/-R license)

MPLS / VPN

Supported (with S-MX150-IR/-R license). LDP; RSVP; VPLS; L2VPN; EVPN

Security

Management

Telnet; SNMP v1/v2/v3; SSH; NETCONF

Power Supply Unit (PSU)

AC PSU

DC PSU

Not supported

Compatible Interface Cards (MIC)

Not supported
