Router Juniper MX5 Available to Quote:

MX5-T-AC; MX5-T-DC

Request a Quote
Description Specifications Additional materials

High-performance 20G Juniper MX5 Series Edge Router, designed for corporate networks, and service providers.

Juniper MX5 router is equipped with 1 slot for MIC interface cards, and 1 slot for multiservice MS-MIC card.

Additionally MX5 supports 4 x 10G (XFP) ports and second slot for MIC interface cards on the front panel of the chassis which could be activated by license.

The MX5 router runs on the Juniper Networks JunOS operating system and the Trio chipset, supports automation, subscriber services, and a comprehensive set for routing.

General All
Interfaces
1
MX5-T-AC/DC:
  • 2 Expansion slots on the front panel (bundle includes 20-Port 1GbE (SFP) MIC card) (license is required to activate one of 2 slots);
  • 1 Expansion slot on the rear panel;
  • 4-port 10GbE (XFP) on the front panel (license is required to activate 4 ports);
  • 1-Port out-of-band management 10/100/1000MbE (RJ45);
  • 1-Port AUX (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 2-Port Clock IN (BITS) (RJ45) on the front panel;
  • 1-Port Clock OUT (BNC) (10 MHz) on the rear panel;
  • 1-Port Sync OUT (BNC) (1 PPS) on the rear panel
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
87.6 (2U) x 445 х 596
(3.45 (2U) x 17.52 x 23.46 in)
4
Maximum Weight (kg)
13.7 (30.2 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)
MX5-T-AC: 376
MX5-T-DC: 320
9
Acoustic noise (dB)

70

10
Performance
11
Switching Bandwidth (Gbit/s)

20

12
Forwarding Rate (Mp/s)

55

13
Layer 2 Features
14
MAC Address Table (entries)

500,000

15
Layer 3 Features
16
Routing Table (prefixes)
Routing Table (RIB):
Forwarding Table (FIB):
17
IP Routing

Static Routing; BGP; IS-IS; OSPFv2

18
MPLS / VPN
19

MPLS; VPLS; BFD; GRE

20
Security
21
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
BRAS: Supported
NAT: Supported
Packet Filtering: Supported
22
Management
23

Telnet; SNMP v1/v2/v3; SSH; NETCONF

24
Power Supply Unit (PSU)
25
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz



26
DC PSU
Type: Removable
Quantity: 2
Rated voltage range: -40 to -72 VDC
27
Compatible Interface Cards (MIC)
28
Model Number
Description
MIC-3D-8OC3OC12-4OC48:
Multirate 8-Port non-channelized OC3-OC12 / 4-Port non-channelized OC48
MIC-3D-4OC3OC12-1OC48:
4-Port non-channelized OC3-OC12 / 1-Port non-channelized OC48
MIC-3D-4CHOC3-2CHOC12:
4-Port channelized OC3 / 2-Port channelized OC12 (down to DS0)
MIC-3D-8CHOC3-4CHOC12:
8-Port channelized OC3 / 4-Port channelized OC12 (down to DS0)
MIC-3D-8OC3-2OC12-ATM:
Multirate 8-Port non-channelized ATM OC3/STM1 or 2-Port non-channelized OC12/STM4 ATM
MIC-3D-4COC3-1COC12-CE:
Multirate circuit emulation MIC. 4-Port channelized OC3 / STM1 (to DS0) or 1-Port channelized OC12/STM4 (to DS0)
MIC-3D-16CHE1-T1-CE:
Circuit Emulation MIC. 16-Port сhannelized E1 / T1
MIC-3D-16CHE1-T1-CE-H:
Circuit Emulation-hardened MIC. 16-Port сhannelized E1 / T1
MIC-3D-8DS3-E3:
4-Port non-channelized DS3 / non-channelized E3
MIC-3D-8CHDS3-E3-B:
8-Port channelized DS3 /  non-channelized E3
MIC-3D-1OC192-XFP:
1-Port OC192
MS-MIC-16G:
Multiservices MIC. Supports CGNAT, Firewall, IPSec
MIC3-3D-20GE-SFP:
20-Port 100/1000MbE (SFP)
MIC-3D-20GE-SFP-E:
20-Port 100/1000MbE (SFP). Environmentally hardened for 0 to 55°C (32 to 131°F) operating temperatures
MIC-3D-20GE-SFP-EH:
20-Port 100/1000MbE (SFP). Environmentally hardened for -40 to +65°C (-40 to +149°F) operating temperatures
MIC-3D-2XGE-XFP:
2-Port 10GbE (XFP)
MIC-3D-40GE-TX:
40-Port 1GbE (RJ45)
29
