MX80-P-AC; MX80-P-DC
MX80-T-AC; MX80-T-DC
Request a QuoteHigh-performance 80G Juniper Networks MX80 Series Edge Router, designed for corporate networks, and service providers.
Juniper Networks MX80 router is equipped with 4 x 10G (XFP) ports and 2 slots for MIC interface cards on the front panel, and 1 slot for multiservice MS-MIC card.
The MX80 router runs on the Juniper Networks JunOS operating system and the Trio chipset, supports automation, subscriber services, and a comprehensive set for routing.
|
MX80-P-AC/DC: |
2 Expansion slots on the front panel (bundle includes 20-Port 1GbE (SFP) MIC card with IEEE 1588v2 support);
1 Expansion slot on the rear panel;
4-port 10GbE (XFP) on the front panel;
1-Port out-of-band management 1GbE (RJ45);
1-Port AUX (RJ45);
1-Port console (RJ45);
1-Port USB;
2-Port Clock IN (BITS) (RJ45) on the front panel;
1-Port Clock OUT (BNC) (10 MHz) on the rear panel;
1-Port Sync OUT (BNC) (1 PPS) on the rear panel
|
| MX80-T-AC/DC: |
2 Expansion slots on the front panel (bundle includes 20-Port 1GbE (SFP) MIC card);
1 Expansion slot on the rear panel;
4-port 10GbE (XFP) on the front panel;
1-Port out-of-band management 1GbE (RJ45);
1-Port AUX (RJ45);
1-Port console (RJ45);
1-Port USB;
2-Port Clock IN (BITS) (RJ45) on the front panel;
1-Port Clock OUT (BNC) (10 MHz) on the rear panel;
1-Port Sync OUT (BNC) (1 PPS) on the rear panel
|
5 to 90
| MX80-AC: | 376 |
| MX80-DC: | 320 |
70
80
55
500,000
| Routing Table (RIB): | 3M |
| Forwarding Table (FIB): | 1М |
Static Routing; BGP; IS-IS; OSPFv2
MPLS; VPLS; BFD; GRE
| Local AAA: | Supported |
| RADIUS, TACACS+: | Supported |
| DHCP Server: | Supported |
| BRAS: | Supported |
| NAT: | Supported |
| Packet Filtering: | Supported |
Telnet; SNMP v1/v2/v3; SSH; NETCONF
| Type: | Removable |
| Quantity: | 2 |
| Rated voltage range: | 100 to 240 VAC, 50-60 Hz |
| Type: | Removable |
| Quantity: | 2 |
| Rated voltage range: | -40 to -72 VDC |
|
Model Number
|
Description
|
|
MIC-3D-8OC3OC12-4OC48:
|
Multirate 8-Port non-channelized OC3-OC12 / 4-Port non-channelized OC48
|
|
MIC-3D-4OC3OC12-1OC48:
|
4-Port non-channelized OC3-OC12 / 1-Port non-channelized OC48
|
|
MIC-3D-4CHOC3-2CHOC12:
|
4-Port channelized OC3 / 2-Port channelized OC12 (down to DS0)
|
|
MIC-3D-8CHOC3-4CHOC12:
|
8-Port channelized OC3 / 4-Port channelized OC12 (down to DS0)
|
|
MIC-3D-8OC3-2OC12-ATM:
|
Multirate 8-Port non-channelized ATM OC3/STM1 or 2-Port non-channelized OC12/STM4 ATM
|
|
MIC-3D-4COC3-1COC12-CE:
|
Multirate circuit emulation MIC. 4-Port channelized OC3 / STM1 (to DS0) or 1-Port channelized OC12/STM4 (to DS0)
|
|
MIC-3D-16CHE1-T1-CE:
|
Circuit Emulation MIC. 16-Port сhannelized E1 / T1
|
|
MIC-3D-16CHE1-T1-CE-H:
|
Circuit Emulation-hardened MIC. 16-Port сhannelized E1 / T1
|
|
MIC-3D-8DS3-E3:
|
4-Port non-channelized DS3 / non-channelized E3
|
|
MIC-3D-8CHDS3-E3-B:
|
8-Port channelized DS3 / non-channelized E3
|
|
MIC-3D-1OC192-XFP:
|
1-Port OC192
|
|
MS-MIC-16G:
|
Multiservices MIC. Supports CGNAT, Firewall, IPSec
|
|
MIC3-3D-20GE-SFP:
|
20-Port 100/1000MbE (SFP)
|
|
MIC-3D-20GE-SFP-E:
|
20-Port 100/1000MbE (SFP). Environmentally hardened for 0 to 55°C (32 to 131°F) operating temperatures
|
|
MIC-3D-20GE-SFP-EH:
|
20-Port 100/1000MbE (SFP). Environmentally hardened for -40 to +65°C (-40 to +149°F) operating temperatures
|
|
MIC-3D-2XGE-XFP:
|
2-Port 10GbE (XFP)
|
|
MIC-3D-40GE-TX:
|
40-Port 1GbE (RJ45)
|
