Routers Huawei AR2200 Series Available to Quote:

AR2204-27GE; AR2204-27GE-P;

AR2204-51GE-P; AR2204E;

AR2204XE; AR2220E;

AR2240C; AR2240

Request a Quote
Description Specifications Additional materials

The Huawei AR2200 Series Routers provide flexible routing and switching.

The Huawei AR2200 Series Routers provide a wide variety of interfaces.

General All
Interfaces
1

AR2204-27GE:

  • 4 Expansion slots SIC on the rear panel;
  • 1-Port combo 1GbE (RJ45/SFP) WAN;
  • 1-Port 1GbE (RJ45) WAN;
  • 1-Port out-of-band management 1GbE (RJ45);
  • 24-Port 1GbE (RJ45) LAN / WAN;
  • 1-Port USB;
  • 1-Port console (RJ45)

AR2204-27GE-P:

  • 4 Expansion slots SIC on the rear panel;
  • 1-Port combo 1GbE (RJ45/SFP) WAN;
  • 1-Port 1GbE (RJ45) WAN;
  • 1-Port out-of-band management 1GbE (RJ45);
  • 16-Port 1GbE (RJ45) LAN / WAN;
  • 8-Port 1GbE (RJ45) PoE LAN / WAN;
  • 1-Port USB;
  • 2-Port PoE power jack;
  • 1-Port console (RJ45)
AR2204-51GE-P:
  • 4 Expansion slots SIC on the rear panel;
  • 1-Port combo 1GbE (RJ45/SFP) WAN;
  • 1-Port 1GbE (RJ45) WAN;
  • 1-Port out-of-band management 1GbE (RJ45);
  • 40-Port 1GbE (RJ45) LAN / WAN;
  • 8-Port 1GbE (RJ45) PoE LAN / WAN;
  • 1-Port USB;
  • 2-Port PoE power jack;
  • 1-Port console (RJ45)
AR2204E:
  • 4 Expansion slots SIC on the rear panel;
  • 1-Port combo 1GbE (RJ45/SFP) WAN;
  • 1-Port 1GbE (RJ45) WAN;
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB;
  • 1-Port console (RJ45)
AR2204XE:
  • 4 Expansion slots SIC on the rear panel;
  • 2 SATA HDD slots;
  • 2-Port 10GbE (SFP+) WAN;
  • 10-Port 1GbE (SFP) WAN;
  • 7-Port 1GbE (RJ45) PoE WAN;
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB;
  • 2-Port PoE power jack;
  • 1-Port console (RJ45)
AR2220E:
  • 4 Expansion slots SIC on the rear panel;
  • 2 Expansion slots WSIC on the rear panel;
  • 1-Port combo 1GbE (RJ45/SFP) WAN;
  • 2-Port 1GbE (RJ45) WAN;
  • 2-Port USB;
  • 1-Port RPS;
  • 1 slot micro SD;
  • 1-Port console (RJ45/miniUSB)
AR2240C:
  • 4 Expansion slots SIC on the rear panel;
  • 2 Expansion slots WSIC on the rear panel;
  • 2 Expansion slots XSIC on the rear panel;
  • 4-Port 1GbE (SFP) WAN;
  • 4-Port 1GbE (RJ45) WAN;
  • 2-Port combo 1GbE (RJ45/SFP) WAN;
  • 1 slot micro SD;
  • 1-Port USB;
  • 1-Port console (RJ45/miniUSB)
AR2240:
  • 1 control card (SRU) slot on the front panel;
  • 4 Expansion slots SIC on the rear panel;
  • 2 Expansion slots WSIC on the rear panel;
  • 2 Expansion slots XSIC on the rear panel
2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
AR2204XE:
AR2220E:
44.5 (1U) x 442 x 420
(1.8 (1U) x 17.4 x 16.5)
AR2240C:
AR2240:
88.1 (2U) x 442 x 470
(3.47 (2U) x 17.4 x 18.5)
4
Maximum Weight (kg)/(lbs)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
AR2204XE:
AR2220E:
5.0 (11.02)
AR2240C:
AR2240:
8.85 (19.51)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 90

7
Operating Temperature (°C)/(°F)

0 to 45 (32 to 113)

8
Maximum power consumption (W)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
60
AR2204XE:
AR2220E:
150
AR2240C:
AR2240:
700
9
Acoustic noise (dB)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
AR2204XE:
AR2220E:
60
AR2240C:
AR2240:
65
10
WLAN
11

Not supported

12
AP Management Feature
13
Maximum AP Supported:

AR2204-27GE:
AR2204-27GE-P:
AR2204-51GE:
AR2204E:
12 (with AC License)
AR2220E:
16 (with AC License)
AR2240C:
32 (with AC License)
AR2204XE:
32 (with AC License
AR2240:
128 (with AC License) (with SRU400)
Compatible AP:
AP6010SN-GN; AP6010DN-AGN; AP6310SN-GN; AP6510DN-AGN;
AP6610DN-AGN; AP7110SN-GN; AP7110DN-AGN; AP5010SN-GN;
AP5010DN-AGN; AP3010DN-AGN; AP6510DN-AGN-US; AP6610DN-AGN-US; AP5030DN; AP5130DN; AP7030DE; AP2010DN; AP8130DN; AP8030DN; AP9330DN; AP4030DN; AP4130DN; AP3030DN; AP2030DN; AP9131DN; AP3010DN-V2
14
Performance
15
Switching Bandwidth (Gbit/s)
AR2204E:
AR2220E:
3

AR2240C:

10
AR2204-27GE:
AR2204-27G-P:
27
AR2204XE:
38

AR2204-51GE-P:

51

AR2240:

80
16
MAC Address Table (entries)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
2048
AR2240C:
AR2220E:
4096
AR2204XE:
AR2240:
819
17
ARP Table (entries)
AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
2000
AR2240C:
AR2220E:
4000
AR2204XE:
6000
AR2240:
16,000 (with SRU400)
18
Layer 2 Features
19
VLAN
IEEE 802.1Q:

AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
128
AR2240C:
AR2220E:
AR2204XE:
AR2240:
4094
20
Layer 3 features
21
Routing Table (prefixes)
Routing Table (RIB):

AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
30,000
AR2220E:
80,000
AR2240C:
300,000
AR2204XE:
500,000
AR2240:
1M (with SRU400)
Forwarding Table (FIB):

AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
30,000
AR2220E:
80,000
AR2240C:
300,000
AR2204XE:
500,000
AR2240:
1M (with SRU400)
22
IP Routing

Static Routing; BGP; IS-IS; OSPFv2

23
MPLS / VPN
24

MPLS LDP; GRE; L3VPN; L2VPN

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
BRAS: Supported
NAT: Supported
Packet Filtering: Supported
27
Management
28

Telnet; SNMP v1/v2/v3; SSH; NETCONF; Web

29
Power Supply Unit (PSU)
30
AC PSU
Type:

AR2204-27GE:
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
AR2204XE:
AR2220E:
Built-in
AR2240C:
AR2240:
Removable
Quantity:

AR2204-27GE:
AR2220E:
1
AR2204-27G-P:
AR2204-51GE-P:
AR2204E:
AR2204XE:
AR2240C:
AR2240:
2
Rated voltage range:
100 to 240 VAC, 50-60 Hz
31
DC PSU
Type:

AR2240C:
AR2240:
Removable
Quantity:

AR2240C:
AR2240:
2
Rated voltage range:
-40 to -72 VDC
32
PoE (Power over Ethernet)
33
Supported by:
AR2204XE;
AR2204-27GE-P;
AR2204-51GE-P;
AR2240C;
AR2240
PoE (802.3af) (15W per port):
AR2204-27GE-P:
AR2204-51GE-P:
4 ports
AR2204XE:
7 ports
AR2240C:
AR2240:
56 ports

PoE+ (802.3аt) (30W per port):
AR2204-27GE-P:
AR2204-51GE-P:
2 ports
AR2204XE: 5 ports
AR2240C:
AR2240:
28 ports

PoE++ (802.3bt) (60W per port): Not supported

PoE++ (802.3bt) (90W per port): Not supported
34
Compatible Control Cards (SRU)
35
Model Number
Description
SRU40:
Control card for AR2240
CPU: 8-core, 600 MHz , Memory: 2 GB, Flash: 16 MB
SRU80:
Control card for AR2240
CPU: 12-core, 750 MHz , Memory: 2 GB, Flash: 16 MB
SRU100E:
Control card for AR2240
CPU: 12-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU200:
Control card for AR2240
CPU: 32-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU200E:
Control card for AR2240
CPU: 12-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
SRU400:
Control card for AR2240
CPU: 32-core, 1.2 GHz , Memory: 4 GB, Flash: 16 MB
36
Compatible Expansion Cards SIC
37
SIC Ethernet cards
Model Number
Description
4ES2G-S:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2220E / AR2240C / AR2240
  • 4-Port 1GbE (RJ45)
4ES2GP-S:
Ethernet LAN card for AR2240C / AR2240
  • 4-Port 1GbE (RJ45) PoE
1GEC:
Ethernet WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port combo 1GbE (RJ45/SFP)
2FE:
Ethernet WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2-Port 100MbE (RJ45)
38
SIC E1/T1 cards
Model Number
Description
1E1/T1-M:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port CE1/CT1/PRI/VE1 (DB9)
2E1/T1-M:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2-Port CE1/CT1/PRI/VE1 (DB9)
1E1/T1-F:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port E1/T1-F (DB9)
2E1/T1-F:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2-Port E1/T1-F (DB9)
39
SIC Sync WAN cards
Model Number
Description
1SA:
Sync WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port SA (DB28)
2SA:
Sync WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2-Port SA (DB28)
40
SIC 3G/LTE cards
Model Number
Description
3G-HSPA+7:
3G card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x 3G antennas (SMA);
  • 1-Port miniUSB
3G-EVDO:
EVDO card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x 3G antennas (SMA);
  • 1-Port miniUSB
1LTE-L:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA);
  • 1-Port miniUSB
1LTE-LV:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA);
  • 1-Port miniUSB
1LTEC:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA);
  • 1-Port miniUSB
1LTE-Lt:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA)
1LTE-Lt-7:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA)
1LTE-Lo:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA)
1LTE-Lc:
LTE card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2 x LTE antennas (SMA)
41
SIC POS/CPOS cards
Model Number
Description
1CPOS-155M:
CPOS card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port CPOS 155 Mbit/s (SFP)
42
SIC ISDN cards
Model Number
Description
1BST:
ISDN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port ISDN S/T (RJ45)
2BST:
ISDN card for AR2220E / AR2240
  • 2-Port ISDN S/T (RJ45)
43
SIC Voice cards
Model Number
Description
4FXS1FXO:
Voice card for AR2220E / AR2240
  • 4-Port FXS (RJ11);
  • 1-Port FXO (RJ11)
4FXO:
Voice card for AR2220E / AR2240
  • 4-Port FXO (RJ11)
1VE1:
Voice card for AR2220E / AR2240
  • 4-Port VE1 (DB9)
44
SIC xDSL cards
Model Number
Description
1ADSL-A/M:
ADSL2+ WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port ADSL-A/M (RJ11)
1ADSL-B/J:
ADSL2+ WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port 1ADSL-B/J (RJ11)
4G.SHDSL:
G.SHDSL WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port G.SHDSL (RJ45)
VDSL2:
VDSL2 WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port VDSL2 (RJ11)
2VDSL2:
VDSL2 WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port 2VDSL2 (RJ11)
45
SIC xPON cards
Model Number
Description
1PON:
xPON WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port GPON/EPON (SFP)
46
SIC Capacitor cards

Model Number

Description

DGP:
Dying Gasp Capacitor Card for AR2220E / AR2240C
  • Power supply time: >100 ms
47
Compatible Expansion Cards WSIC
48
WSIC Ethernet cards
Model Number
Description
8FE1GE:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 8-Port 100MbE (RJ45);
  • 1-Port 1GbE (RJ45)
9ES2:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2220E / AR2240C / AR2240
  • 8-Port 100MbE (RJ45);
  • 1-Port 1GbE (RJ45)
4GE-2S:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2220E / AR2240C / AR2240
  • 4-Port 1GbE (SFP)
4GECS:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240C / AR2240
  • 4-Port combo 1GbE (RJ45/SFP)
2FE:
Ethernet LAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2220E / AR2240C / AR2240
  • 4-Port 100MbE (RJ45)
2X10GL:
Ethernet LAN card for AR2240
  • 4-Port 10GbE (SFP+)
4GEW-T:
Ethernet WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240C / AR2240
  • 4-Port 1GbE (RJ45)
4GEW-S:
Ethernet WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240C / AR2240
  • 4-Port 1GbE (SFP)



49
WSIC E1/T1 cards

Model Number

Description

2E1/T1-M-W:

E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 2-Port CE1/CT1/PRI/VE1 (DB9)

4E1/T1-M:

E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 4-Port CE1/PRI (RJ48)
8E1/T1-M:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 8-Port CE1/PRI (RJ48)
4E1/T1-F:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 4-Port E1-F (RJ48)
8E1/T1-F:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 8-Port E1-F (RJ48)
4E1-IMA:
E1/T1 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 4-Port E1-IMA (RJ48)
50
WSIC E3/T3 cards
Model Number
Description
1E3/CE3/T3/CT3:
E3/T3 card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P  / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port E3 (SMB)
51
WSIC E&M cards
Model Number
Description
6E&M:
E&M card for AR2204XE / AR2220E / AR2240C / AR2240
  • 6-Port E&M (RJ45)
52
WSIC POS/CPOS cards
Model Number
Description
1CPOS-155M-W:
CPOS card for AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port CPOS 155 Mbit/s (SFP)
1STM1:
STM-1 card for AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port STM-1 155 Mbit/s (SFP)
1STM4:
STM-4 card for AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port STM-4 622 Mbit/s (SFP)
4STM1:
STM-1 card for AR2204XE / AR2220E / AR2240C / AR2240
  • 4-Port STM-1 155 Mbit/s (SFP)
53
WSIC Sync WAN cards
Model Number
Description
8SA:
Sync WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 8-Port SA (DB28)
8AS:
Sync WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204E / AR2204XE / AR2220E / AR2240C / AR2240
  • 8-Port Async serial interfaces (RJ45)
54
WSIC ISDN cards

Model Number

Description

2BST-W:
ISDN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240 / AR2220E / AR2240
  • 2-Port ISDN S/T (RJ45)
55
WSIC Voice cards
Model Number
Description
16FXS:
Voice card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240
  • 16-Port FXS (DB68)
32FXS:
Voice card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2220E / AR2240
  • 32-Port FXS (DB68)
56
WSIC xDSL cards
Model Number
Description
1GBIS4W:
G.SHDSL WAN card for AR2204-27GE / AR2204-27GE-P / AR2204-51GE-P / AR2204XE / AR2220E / AR2240C / AR2240
  • 1-Port G.SHDSL (RJ45)
57
Compatible Expansion Cards XSIC
58
XSIC Ethernet cards
Model Number
Description
24GE:
Ethernet LAN card for AR2220E / AR2240C / AR2240
  • 24-Port 1GbE (RJ45)
24ES2GP:
Ethernet LAN card for AR2240C / AR2240
  • 24-Port 1GbE (RJ45) PoE
59
Similar Products
Recently viewed
Agree
This website uses cookies. By continuing to browse the website you are agreeing to accept of cookies Privacy Policy
