Routers Huawei AR502 Series

Routers Huawei AR502 Series Available to Quote:

AR502EG-L; AR502EGW-L

End-of-Sale: AR502G-L-D-H

Request a Quote

Description Specifications Additional materials

Huawei AR502 is a series of industrial routers, supports LTE / 3G for data transfer.

General All

Interfaces

AR502EG-L:	2 x LTE antennas (SMA RF) WAN; 2-Port 1GbE (RJ45) LAN; 1-Port RS485/R422 (5-pin Phoenix terminal block); 1-Port RS232 (DB9); 1-Port DI/DO (RJ45); 1-Port USB; 2 SIM card slots
AR502EGW-L:	2 x LTE antennas (SMA RF) WAN; 2-Port 1GbE (RJ45) LAN; 1 x Wi-Fi antenna (LAN); 1-Port RS485/RS422 (5-pin Phoenix terminal block); 1-Port RS232 (DB9); 1-port DI/DO (RJ45); 1-Port USB; 2 SIM card slots
AR502G-L-D-H:	1-Port 1GbE (RJ45) WAN; 2 x LTE antennas (SMA RF) WAN; 1-Port RS485/RS422 (5-pin Phoenix terminal block); 1-Port RS232 (DB9); 1-Port DI/DO (RJ45); 1-Port USB; 2 SIM card slots

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

44 (1U) x 150 x 100

(1.73 (1U) x 5.91 x 3.94)

Maximum Weight (kg)/(lbs)

0.85 (1.87)

Environmental Conditions

Relative Humidity (%)

5 to 95

Operating Temperature (°C)/(°F)

AR502EG-L:

AR502EGW-L:

-25 to +70 (-13 to +158)

AR502G-L-D-H:

-25 to +65 (-13 to +149)

Maximum power consumption (W)

Acoustic noise

WLAN

3G / LTE

AR502EG-L:	LTE FDD: Band 1/2/3/4/5/7/8/20 DC-HSPA+/HSPA+/HSPA/WCDMA: Band 1/2/5/8 GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
AR502EGW-L:	LTE FDD: Band 1/2/3/4/5/7/8/20 DC-HSPA+/HSPA+/HSPA/WCDMA: Band 1/2/5/8 GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
AR502G-L-D-H:	LTE FDD: Band 1/2/3/4/5/7/8/20 DC-HSPA+/HSPA+/HSPA/WCDMA: Band 1/2/5/8 GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)

Wi-Fi

AR502EGW-L:

Standards/bands supported: 802.11b/g/n, 2.4GHz, 1 x 1 MIMO;
Rate supported: 150 Mbit/s;
Antenna gain: 2.15 dBi

AP Management Feature

Maximum AP Supported:	8
Compatible AP:	AP6010SN-GN; AP6010DN-AGN; AP6310SN-GN; AP6510DN-AGN; AP6610DN-AGN; AP7110SN-GN; AP7110DN-AGN; AP5010SN-GN; AP5010DN-AGN; AP3010DN-AGN; AP6510DN-AGN-US; AP6610DN-AGN-US; AP5030DN; AP5130DN; AP7030DE; AP2010DN; AP8130DN; AP8030DN; AP9330DN; AP4030DN; AP4130DN; AP3030DN; AP2030DN; AP9131DN; AP3010DN-V2

Performance

Switching Bandwidth (Mbit/s)

150

MAC Address Table (entries)

2000

Layer 2 Features

VLAN

IEEE 802.1Q: 128; GVRP

Layer 2 Reliability

STP/RSTP/MSTP

Layer 3 features

Routing Table (prefixes)

Routing Table (RIB):	20,000
Forwarding Table (FIB):	10,000

IP Routing

Static Routing; BGP; IS-IS; OSPFv2

MPLS / VPN

GRE

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
BRAS:	Not supported
NAT:	Not supported
Packet Filtering:	Supported

Management

Telnet; SNMP v1/v2/v3; SSH; CWMP; Web

Power Supply Unit (PSU)

AC PSU

Not supported

DC PSU

Type:	Built-in
Quantity:	1
Rated voltage range:	12 VDC / 24 VDC

Compatible Expansion Cards

Not supported

AR502 Datasheet (en)
