Routers Huawei AR510 Series
Routers Huawei AR510 Series

End-of-Sale

Please see "Similar Products" below.
Description Specifications Additional materials

Huawei AR510 is a series of industrial routers, supports 4G FDD LTE for data transfer and is compatible with 3G network.

General All
Interfaces
1
AR511GW-LAV2M3:
  • 2-Port 1GbE (RJ45) WAN;
  • 1-Port Audio 1 IN / 2 OUT (DB9);
  • 2-Port Video OUT (DVI-I);
  • 1 GPS antenna (SMA RF);
  • 2 LTE antennas (SMA RF);
  • 2 Wi-Fi antennas (SMA);
  • 1-Port USB;
  • 1-Port microUSB;
  • 2 SIM card slots;
  • 1 Micro SD card slot;
  • 1-Port console (microUSB)
AR511CGW-LAV2M3:
  • 2-Port 1GbE (RJ45) WAN;
  • 1-Port Audio 1 IN / 2 OUT (DB9);
  • 2-Port Video OUT (DVI-I);
  • 1 GPS antenna (SMA RF);
  • 2 LTE antennas (SMA RF);
  • 2 Wi-Fi antennas (SMA);
  • 1-Port USB;
  • 1-Port microUSB;
  • 2 SIM card slots;
  • 1 Micro SD card slot;
  • 1-Port console (microUSB)
AR511GW-LM7:
  • 1-Port 1GbE (RJ45) WAN;
  • 1 GPS antenna (SMA RF);
  • 2 LTE antennas (SMA RF);
  • 2 Wi-Fi antennas (SMA);
  • 1-Port USB;
  • 1-Port microUSB;
  • 2 SIM card slots;
  • 1 Micro SD card slot;
  • 1-Interface mSATA (USB 3.0)
  • 1-Port console (microUSB)
AR511GW-L-B3:
  • 1-Port 1GbE (RJ45) WAN;
  • 1-Port Audio IN / OUT (DB9);
  • 2-Port Video OUT (DVI-I);
  • 1 GPS antenna (SMA RF);
  • 2 LTE antennas (SMA RF);
  • 2 Wi-Fi antennas (SMA);
  • 1 DTMB antenna (SMA-K);
  • 1-Port USB;
  • 1-Port microUSB;
  • 2 SIM-card slots;
  • 1 Micro SD card slot;
  • 1-Port console (microUSB)
AR513W-V3M8:
  • 2-Port 1GbE (RJ45) WAN;
  • 1-Port SATA;
  • 1-Port DI / DO (Phoenix terminal block);
  • 1-Interfrace eSATA (eSATA connector);
  • 1-Port VGA (DB15);
  • 2-Port HDMI;
  • 2-Port USB;
  • 2 Wi-Fi antennas (SMA);
  • 1-Port RS485 (RJ45) (reserved for future use);
  • 1-Port Audio (3.5 mm);
  • 1-Port microUSB;
  • 1 Micro SD card slot;
  • 1-Port console (microUSB)
AR515GW-LM9-D:
  • 4-Port 1GbE (M12) WAN;
  • 4-Port 1GbE (M12) LAN;
  • 1-Port VGA (DB15);
  • 2 SIM-card slots;
  • 1-Port DB37 (usage: 4 x RS232; 2 x CAN; 1 x RS465/RS422;  8 x I/O (3 x DI/DO 5 V level; 2 x DI 5 V level; 3 x AI 24 V level; 5V / GND);
  • 2 LTE antennas (SMA);
  • 2 Wi-Fi antennas (SMA);
  • 3-Port USB;
  • 1 GPS antenna (SMA RF);
  • 1-Port HDMI;
  • 1-Port Earphone jack;
  • 1-Port Microphone jack;
  • 1-Port RS485/RS242 (RJ45);
  • 1 HDD expansion slot;
  • 1-Port console (DB9)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
AR511GW-LAV2M3:
AR511CGW-LAV2M3:
AR511GW-LM7:
AR511GW-L-B3:
30.0 x 275.0 x 160
(1.2 x 10.8 x 6.3)
AR513W-V3M8:
40.0 x 275.0 x 180
(1.6 x 10.8 x 7.1)
AR515GW-LM9-D:
68.0 x 406.0 x 270
(2.68 x 15.98 x 10.63)
4
Maximum Weight (kg)/(lbs)
AR511GW-LAV2M3:
AR511CGW-LAV2M3:
AR511GW-LM7:
AR511GW-L-B3:
1.3 (2.87)
AR513W-V3M8:
2.3 (5.07)
AR515GW-LM9-D:
6.9 (15.2)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)/(°F)
AR511GW-LAV2M3; AR511CGW-LAV2M3:
-10 to +60 (14 to 140)
AR511GW-LM7:
0 to 50 (32 to 122)
AR511GW-L-B3; AR513W-V3M8:
-10 to +60 (14 to 140)
AR515GW-LM9-D:
  • With Hard Disk Drive (HDD) installed: 0 to 45 (32 to 113)
  • With a Solid State Drives (SSD) installed: –25 to +60 (-13 to 140)
  • With no Hard Disk Drive (HDD) installed: –25 to +60 (-13 to 140)
8
Maximum power consumption (W)
AR511GW-LAV2M3; AR511CGW-LAV2M3: 30
AR511GW-LM7: 25
AR511GW-L-B3; AR513W-V3M8: 30
AR515GW-LM9-D: 72
9
Acoustic noise

0

10
Performance
11
Switching Bandwidth (Mbit/s)

75

12
MAC Address Table (entries)

256

13
WLAN
14
3G / LTE
AR511GW-LAV2M3:
  • LTE FDD: Band 1/2/3/5/7/8/20
  • WCDMA/HSDPA/HSUPA/HSPA+: Band 1/2/5/8
  • GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
AR511CGW-LAV2M3:
  • FDD LTE: Band 1/3/8
  • TDD LTE: Band 38/39/40/41
  • HSPA+: Band 1/2/5/8
  • TD-SCDMA: Band 34/39
  • GSM/GPRS/EDGE: 900/1800/1900 (MHz)
AR511GW-LM7:
  • LTE FDD: Band 1/2/3/5/7/8/20
  • WCDMA/HSDPA/HSUPA/HSPA+: Band 1/2/5/8
  • GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
AR511GW-L-B3:
  • LTE FDD: Band 1/2/3/5/7/8/20
  • WCDMA/HSDPA/HSUPA/HSPA+: Band 1/2/5/8
  • GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
AR515GW-LM9-D:
  • LTE FDD: Band 1/2/3/5/7/8/20
  • WCDMA/HSDPA/HSUPA/HSPA+: Band 1/2/5/8
  • GSM/GPRS/EDGE: 850/900/1800/1900 (MHz)
15
Wi-Fi
AR511GW-LAV2M3:
  • Standards/bands supported: 802.11b/g/n, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 300 Mbit/s;
  • Antenna gain: 2.15 dBi
AR511CGW-LAV2M3:
  • Standards/bands supported: 802.11b/g/n, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 300 Mbit/s;
  • Antenna gain: 2.15 dBi
AR511GW-LM7:
  • Standards/bands supported: 802.11b/g/n, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 300 Mbit/s;
  • Antenna gain: 2.15 dBi
AR511GW-L-B3:
  • Standards/bands supported: 802.11b/g/n, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 300 Mbit/s;
  • Antenna gain: 2.15 dBi
AR513W-V3M8:
  • Standards/bands supported: 802.11b/g/n, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 300 Mbit/s;
  • Antenna gain: 2.15 dBi
AR515GW-LM9-D:
  • Standards/bands supported: 802.11b/g/n/ac, 2.4GHz, 5.0 GHz; 2 x 2 MIMO;
  • Rate supported: 867 Mbit/s;
  • Antenna gain: 2.15 dBi
16
AP Management Feature
17
Maximum AP Supported:
8
Compatible AP:
AP6010SN-GN; AP6010DN-AGN; AP6310SN-GN; AP6510DN-AGN;
AP6610DN-AGN; AP7110SN-GN; AP7110DN-AGN; AP5010SN-GN;
AP5010DN-AGN; AP3010DN-AGN; AP6510DN-AGN-US; AP6610DN-AGN-US; AP5030DN; AP5130DN; AP7030DE; AP2010DN; AP8130DN; AP8030DN; AP9330DN; AP4030DN; AP4130DN; AP3030DN; AP2030DN; AP9131DN; AP3010DN-V2
18
Layer 2 Features
19
VLAN

IEEE 802.1Q: 64; GVRP

20
Layer 2 Reliability

STP/RSTP/MSTP

21
Layer 3 features
22
Routing Table (prefixes)
Routing Table (RIB): 2000
Forwarding Table (FIB): 2000
23
IP Routing

Static Routing; IS-IS; OSPFv2

24
MPLS / VPN
25

GRE

26
Security
27
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server Supported
BRAS: Not supported
NAT: Not supported
Packet Filtering: Supported
28
Management
29

Telnet; SNMP v1/v2/v3; SSH; Web

30
Power Supply Unit (PSU)
31
AC PSU

Not supported

32
DC PSU
Type: Built-in
Quantity: 1
Rated voltage range:

AR511GW-LAV2M3:

AR511CGW-LAV2M3:

AR511GW-LM7:

AR511GW-L-B3:

 12 VDC / 24 VDC
AR513W-V3M8: 12 VDC
AR515GW-LM9-D: 24 VDC
33
Compatible Expansion Cards
34

Not supported

35

AR510 Datasheet (en)
