Switch Juniper QFX5220-32СD

Switch Juniper QFX5220-32СD Available to Quote:

QFX5220-32CD-AFO; QFX5220-32CD-AFI

QFX5220-32CD-D-AFO; QFX5220-32CD-D-AFO

Request a Quote

Description Specifications Additional materials

The fixed configuration Juniper Ntworks QFX5220-32CD switch provide 32 х 40/100/400G (QSFP-DD) ports.

General All

Interfaces

QFX5220-32CD:

32-Port 40/100/400GbE (QSFP-DD/QSFP28/QSFP+);
2-Port 10GbE (SFP+);
1-Port out-of-band management 1GbE (RJ45);
2-Port console (RJ45);
1-Port USB;
1-Port ToD (RJ45);
2-Port PTP (SMB)

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

43 (1U) x 438 x 535.9

(1.72 (1U) x 17.26 x 21.1)

Maximum Weight (kg)/(lbs)

11.11 (24.5)

Environmental Conditions

Relative Humidity (%)

5 to 90

Operating Temperature (°C)/(°F)

0 to 40 (32 to 104)

Maximum Power Consumption (W)

958

Acoustic noise (dB)

Performance

Switching Bandwidth (Tbit/s)

25.6

Forwarding Rate (Bp/s)

MAC Address Table (entries)

8192

ARP Table (entries)

32,000

Layer 2 Features

VLAN

IEEE 802.1Q: 3952; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	4096
Multicast VLAN (MVR):	Supported
Multicast Routing:	PIM-SM; PIM-DM; PIM-SSM; MSDP

Layer 3 features

Routing Table (routes)

IPv4:	336,000
IPv6:	130,000

IP Routing

Static Routing, RIPv1/2, OSPF, IS-IS (with Advanced Services license), BGP (with Advanced Services license)

MPLS / VPN

Supported (with Premium Services License)

VXLAN

Layer 2 Gateway, Layer 3 Gateway, BGP-EVPN

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; Syslog; NTP; Junos XML; Python

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	4
Rated voltage range:	110 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	4
Rated voltage range:	-36 to -72 VDC

PoE (Power over Ethernet)

Not supported

Compatible Expansion Cards

Not supported

QFX5220-32CD Datasheet (en)
