Switches Extreme Networks VSP7200 Series
Switches Extreme Networks VSP7200 Series Available to Quote:

7254XSQ; 7254XTQ

 Request a Quote
Description Specifications Additional materials

The compact Extreme Networks VSP7200 Series platform built on the next generation chipset is perfect for data centers and corporate networks. The switches provide 10GbE / 40GbE connectivity, high-speed Ethernet as a Top-of-Rack (ToR) connection.

The chipset is designed to provide data rates on a Tbit/s scale with a fully integrated 10, 40, 100GbE ASIC architecture, which provides numerous capabilities for network distribution / aggregation.

General All
Interfaces
1
VSP 7254XSQ:
  • 48-Port 10GbE (SFP+);
  • 6-Port 40GbE (QSFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB
VSP 7254XTQ:
  • 48-Port 10GbE (RJ45);
  • 6-Port 40GbE (QSFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
44 (1U) x 440 x 464
(1.75 (1U) x 17.3 x 18.25 in)
4
Maximum Weight (kg)

8.50 (18.74 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

10 to 95

7
Operating Temperature (°C)

0 to 45 (32 to 113 °F)

8
Maximum Power Consumption (W)

800

9
Acoustic noise (dB)

70

10
Performance
11
Switching Bandwidth (Tbit/s)

2.56

12
Forwarding Rate (Mp/s)

1428

13
MAC Address Table (entries)

224,000

14
ARP Table (entries)

32,000

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4059

17
Layer 2 Reliability

STP/RSTP/MSTP

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 4059
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SM, PIM-SSM
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 15,000
IPv6: 7000
22
IP Routing

Static Routing; RIPv1/2; OSPFv2; BGP

23
MPLS / VPN
24

L2/L3 Virtual Service Networks (VSNs)

25
Security
26
Local AAA: Supported
RADIUS TACACS+: Supported
DHCP Server: Not supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; SNMP v1/v2/v3; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz
31
DC PSU
Type: Removable
Quantity: 2
Rated voltage range: -48 to -60 VDC
32
PoE (Power over Ethernet)
33

Not supported

34
Compatible expansion cards
35

Not supported

36

VSP7200 Datasheet (en)
