Switches Extreme Networks X870 Series

Switches Extreme Networks X870 Series Available to Quote:

X870-32c; X870-96x-8c

Request a Quote

Description Specifications Additional materials

Extreme Networks managed switches Summit X870 series with a high port density of 10 GbE, 25 GbE, 40 GbE, 50 GbE, 100 GbE are used in data centers and corporate networks.

X870 switches in a compact 1U form factor have fixed ports - 32 * 100GbE or 24 * 40GbE, with support for IPv4 / IPv6, MPLS, OSPF, BGP.

General All

Interfaces

X870-32c:	32-Port 100GbE (QSFP28); 1-Port console (RJ45); 1-Port console (microUSB); 1-Port out-of-band management 1GbE (RJ45); 1-Port USB (microUSB)
X870-96x-8c:	24-Port 40GbE (QSFP+) + 8-Port 10/25/40/50/100GbE (QSFP28) or 96-Port 10GbE (SFP+) + 8-Port 10/25/40/50/100GbE (QSFP28); 1-Port console (RJ45); 1-Port console (microUSB); 1-Port out-of-band management 1GbE (RJ45); 1-Port USB (microUSB)

Physical Parameters

Dimensions (HxWxD) (mm)

43 (1U) x 440 x 520

(1.7 (1U) x 17.3 x 20.5 in)

Maximum Weight (kg)

8.6 (18.9 lbs)

Environmental Conditions

Relative Humidity (%)

10 to 95

Operating Temperature (°C)

0 to 45 (32 to 113 °F)

Maximum Power Consumption (W)

473

Acoustic noise (dB)

76.5

Performance

Switching Bandwidth (Tbit/s)

6.4

MAC Address Table (entries)

136,000

ARP Table (entries)

6000

Layer 2 Features

VLAN

IEEE 802.1Q: 4092. QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	4096
Multicast VLAN (MVR):	Supported
Multicast Routing:	Not supported

Layer 3 features

Routing Table (routes)

IPv4:	192,000
IPv6:	64,000

IP Routing

Static Routing; RIPv1/2; OSPFv2 (with Core license); IS-IS (with Core license); BGP (with Core license); MBGP (with Core license)

MPLS / VPN

Supported (with MPLS license)

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Not supported
DHCP Relay option82:	Not supported
DHCP Snooping:	Not supported
Loop detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; LLDP; sFlow; IPFIX; OpenFlow (with Open Flow license); SNMP v1/v2/v3; Syslog; NTP

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	110 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-48 to -60 VDC

PoE (Power over Ethernet)

Not supported

Compatible expansion cards

Not supported

X870 Datasheet (en)
