Switches Huawei CE6870 Series
Switches Huawei CE6870 Series Available to Quote:

CE6870-48T6CQ-EI; CE6870-48S6CQ-EI;

End-of-Sale:

CE6870-24S6CQ-EI

 Request a Quote
Description Specifications Additional materials

Huawei CE6870 Series Gigabit Switches with 10GbE fixed ports are great for data centers and large campus networks.

The modern Huawei VRP8 software platform provides comprehensive data center maintenance functions with iStack support. iStack allows you to combine several switches into a single logical device, you can increase ports and throughput by simply adding the switch to the stack.

General All
Interfaces
1
CE6870-48T6CQ-EI:

  • 48-Port 1/10GbE (RJ45);
  • 6-Port 40/100GbE (QSFP28);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB
CE6870-48S6CQ-EI:
  • 48-Port 1/10GbE (SFP+);
  • 6-Port 40/100GbE (QSFP28);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB
CE6870-24S6CQ-EI:
  • 24-Port 1/10GbE (SFP+);
  • 6-Port 40/100GbE (QSFP28);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 1GbE (RJ45);
  • 1-Port USB
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
43.6 (1U) x 442 x 420
(1.72 (1U) x 17.4 x 16.53 in)
4
Maximum Weight (kg)
CE6870-48T6CQ-EI: 9.8 (21.6 lbs)
CE6870-48S6CQ-EI:
 8.7 (19.2 lbs)
CE6870-24S6CQ-EI:
8.5 (18.7 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)
CE6870-48T6CQ-EI: 394
CE6870-48S6CQ-EI:
 333
CE6870-24S6CQ-EI:
258
9
Acoustic noise (dB)

52

10
Performance
11
Switching Bandwidth (Tbit/s)
CE6870-48T6CQ-EI:
CE6870-48S6CQ-EI:
 2.16
CE6870-24S6CQ-EI:
 1.68
12
Forwarding Rate (Mp/s)

720

13
MAC Address Table (entries)

750,000

14
ARP Table (entries)

750,000

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094.  QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; ERPS (G.8032); TRILL; VXLAN

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 4096
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SM, MBGP, MSDP
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 380,000
IPv6: 128,000
22
IP Routing

Static Routing, RIPv1/2, OSPFv2, IS-IS, BGP, VRRP

23
MPLS / VPN
24

Supported

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; NETCONF; Netstream; sFlow; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 90 to 290 VAC, 50-60 Hz
31
DC PSU
Type: Removable
Quantity: 2
Rated voltage range: -38.4 to -72 VDC
32
PoE (Power over Ethernet)
33

Not supported

34
Compatible Expansion Cards
35

Not supported

36

CE6870 Datasheet (en)
