Switches Huawei CloudEngine 16800 Series Available to Quote:
CE16804;
CE16808;
CE16816

Request a Quote
Description Specifications Additional materials

Huawei CloudEngine 16800 series switches for data centers.

The CloudEngine 16800 series switches includes 3 models:

CE16804 which can provide a maximum of 144 x 100GE ports;

CE16808 which can provide a maximum of 288 x 100GE ports;

CE16816 which can provide a maximum of 576 x 100GE ports.

General All
Interfaces
1
CE16804:
  • 2 Control Card slots (MPU);
  • 6 Switch Fabric slots (SFU);
  • 4 Service Card slots (LPU)
CE16808:
  • 2 Control Card slots (MPU);
  • 6 Switch Fabric slots (SFU);
  • 8 Service Card slots (LPU)
CE16816:
  • 2 Control Card slots (MPU);
  • 6 Switch Fabric slots (SFU);
  • 16 Service Card slots (LPU)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
CE16804:
438 (10U) x 483 x 985
(17.24 (10U) x 19.01 x 38.77)
CE16808:
703 (16U) x 483 x 985
(27.67 (17U) x 19.01 x 38.77)
CE16816:
1436 (32U) x 483 x 1144
(56.53 (32U) x 19.01 x 45.03)
4
Maximum Weight (kg)/(lbs)
CE16804: 87.8 (193.7)
CE16808: 123.9 (273.4)
CE16816: 252.8 (557.8)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 85

7
Operating Temperature (°C)/(°F)

0 to 40 (32 to 104)

8
Maximum Power Consumption (W)
CE16804:
18,000
CE16808:
30,000
CE16816: 60,000
9
Acoustic noise (dB)

78

10
Performance
11
Switching Bandwidth (Tbit/s)
CE16804: 43
CE16808: 86
CE16816: 173
12
Forwarding Rate (Mp/s)
CE16804:
11,280
CE16808:
22,560
CE16816: 45,120
13
MAC Address Table (entries)
Card Series Specifications

CEL48XSFD1-G:

CEL24LQFD1-G:

CEL36LQFD1-G:

176,000 (large-mac mode)

CEL18CQFD-G:

CEL36CQFD-G:

256,000 (large-mac mode)
14
ARP Table (entries)

256,000 (large-route mode)

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094.  GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; ERPS (G.8032); TRILL

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 4096
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SM; PIM-DM; MBGP; MSDP
20
Layer 3 Features
21
Routing Table (routes)
FIB IPv4: 256,000 (large-route mode)
FIB IPv6: 80,000 (large-route mode)
22
IP Routing

Static Routing, RIPv1/2, OSPF, IS-IS, BGP

23
MPLS / VPN
24

Not supported

25
VXLAN
26

Supported

27
Security
28
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
29
Management
30

Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; RMON; Syslog; NTP

31
Power Supply Unit (PSU)
32
AC PSU
Type: Removable
Quantity:
CE16804: 6
CE16808: 10
CE16816: 20
Rated voltage range: 176 to 290 VAC, 50-60 Hz
33
DC PSU
Type: Removable
Quantity:
CE16804: 6
CE16808: 10
CE16816: 20
Rated voltage range: -40 to -72 VDC, 188 to 288 VDC, 260 to 400 VDC
34
PoE (Power over Ethernet)
35

Not supported

36
Compatible Control Cards
37
Model Number Description
CE-MPUD-HALF:

Control Card for CE16804, CE16808

CE-MPUE-HALF:

Control Card for CE16804, CE16808

CE-MPUD-FULL:

Control Card for CE16816

CE-MPUE-FULL:

Control Card for CE16816

38
Compatible Switch Fabric Cards
39
Model Number Description
CE-SFU04G-G:

Switch fabric unit for CE16804

CE-SFU04F-G:

Switch fabric unit for CE16804

CE-SFU08G-G: Switch fabric unit for CE16808
CE-SFU08F-G: Switch fabric unit for CE16808
CE-SFU16G-G: Switch fabric unit for CE16816
CE-SFU16F-G: Switch fabric unit for CE16816
40
Compatible Service Cards
41
10GbE Service Cards
Model Number
Description
CEL48XSFD-G:
10GbE service card for CE168084, CE16808, CE16816
  • 48-Port 10GbE (SFP+)
42
40GbE Service Cards
Model Number
Description
CEL24LQFD-G:
40GbE service card for CE168084, CE16808, CE16816
  • 24-Port 40GbE (QSFP+)
CEL36LQFD-G:
40GbE service card for CE168084, CE16808, CE16816
  • 36-Port 40GbE (QSFP+)
43
100GbE Service Cards
Model Number
Description
CEL18CQFD-G
100GbE service card for CE168084, CE16808, CE16816
  • 18-Port 100GbE (QSFP28)
CEL36CQFD-G:
100GbE service card for CE168084, CE16808, CE16816
  • 36-Port 100GbE (QSFP28)
