Switches Huawei S2300TP-EI Series

End-of-Sale

Please see "Similar Products" below.

Description Specifications Additional materials

A series of access layer manageable switches

General All

Interfaces

S2309TP-EI-AC/DC:	8-Port 10/100MbE(RJ45); 1-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S2318TP-EI-AC/DC:	16-Port 10/100MbE(RJ45); 2-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S2326TP-EI-AC/DC:	24-Port 10/100MbE (RJ45); 2-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S2328P-EI-AC:	24-Port 10/100MbE (RJ45); 4-Port 100/1000MbE (SFP); 1-Port console (RJ45)
S2352P-EI:	48-Port 10/100MbE (RJ45); 2-Port 100/1000MbE (SFP); 2-Port 1GbE (SFP); 1-Port console (RJ45)
S2309TP-PWR-EI:	8-Port 10/100MbE (RJ45) PoE; 1-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S2326TP-PWR-EI:	24-Port 10/100MbE (RJ45) PoE; 2-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

S2309TP-EI-AC/DC:	43.6 (1U) х 250 х 180 (1.72 (1U) x 9.84 x 7.09)
S2318TP-EI-AC/DC: S2326TP-EI-AC/DC: S2328P-EI-AC: S2352P-EI: S2309TP-PWR-EI:	43.6 (1U) х 442 х 220 (1.72 (1U) x 17.4 x 8.66)
S2309TP-PWR-EI:	43.6 (1U) х 320 х 220 (1.72 (1U) x 12.59 x 8.66)
S2326TP-PWR-EI:	43.6 (1U) х 442 х 420 (1.72 (1U) x 17.4 x 16.54)

Maximum Weight (kg)/(lbs)

S2309TP-EI-AC/DC:	1.4 (3.09)
S2318TP-EI-AC/DC: S2326TP-EI-AC/DC:	2.4 (5.3)
S2328P-EI-AC:	2.0 (4.4)
S2352P-EI:	3.0 (6.61)
S2309TP-PWR-EI:	2.5 (5.51)
S2326TP-PWR-EI:	5.0 (11.02)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)/(°F)

-5 to +50 (23 to 122)

Maximum Power Consumption (W)

S2309TP-EI-AC/DC:	12.8
S2318TP-EI-AC/DC:	14.5
S2326TP-EI-AC/DC:	15.5
S2328P-EI-AC:	10.47
S2352P-EI:	38
S2309TP-PWR-EI:	154
S2326TP-PWR-EI:	808

Acoustic noise (dB)

S2309TP-EI-AC/DC: S2309TP-PWR-EI: S2318TP-EI-AC/DC: S2326TP-EI-AC/DC: S2328P-EI-AC:	0
S2352P-EI:	52
S2326TP-PWR-EI:	62.5

Performance

Switching Bandwidth (Gbit/s)

S2309TP-EI-AC/DC: S2309TP-PWR-EI:	3.6
S2318TP-EI-AC/DC:	7.2
S2326TP-EI-AC/DC: S2326TP-PWR-EI:	8.8
S2328P-EI-AC:	12.8
S2352P-EI:	17.6

Forwarding Rate (Mp/s)

S2309TP-EI-AC/DC: S2309TP-PWR-EI:	2.7
S2318TP-EI-AC/DC:	5.4
S2326TP-EI-AC/DC: S2326TP-PWR-EI:	6.6
S2328P-EI-AC:	9.6
S2352P-EI:	13.2

MAC Address Table (entries)

8000

ARP Table (entries)

256

Layer 2 Features

VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP; RRPP

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	512
Multicast VLAN (MVR):	Supported
Multicast Routing:	Not supported

Layer 3 Features

Routing Table (routes)

IPv4:	16
IPv6:	16

IP Routing

Static Routing

MPLS / VPN

Not supported

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Not supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop Detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

Power Supply Unit (PSU)

AC PSU

Type:
S2309TP-EI-AC: S2318TP-EI-AC: S2326TP-EI-AC: S2328P-EI-AC: S2352P-EI:	Built-in
S2326TP-PWR-EI:	Removable
Quantity:
S2309TP-EI-AC: S2318TP-EI-AC: S2326TP-EI-AC: S2352P-EI: S2328P-EI-AC:	1
S2326TP-PWR-EI:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:
S2309TP-EI-DC: S2318TP-EI-DC: S2326TP-EI-DC:	Built-in
Quantity:
S2309TP-EI-DC: S2318TP-EI-DC: S2326TP-EI-DC:	1
Rated voltage range:	-48 to -60 VDC

PoE (Power over Ethernet)

Supported by:	S2309TP-PWR-EI, S2326TP-PWR-EI
PoE (802.3af) (15W per port):
S2309TP-PWR-EI	8 ports
S2326TP-PWR-EI:	8 ports (with 250W PSU)
S2326TP-PWR-EI:	24 ports (with 500W PSU)

PoE+ (802.3аt) (30W per port):
S2309TP-PWR-EI	4 ports
S2326TP-PWR-EI:	4 ports (with 250W PSU)
S2326TP-PWR-EI:	12 ports (with 500W PSU)
S2326TP-PWR-EI:	24 ports (with 2 x 500W PSU)

PoE++ (802.3bt) (60W per port):	Not supported

PoE++ (802.3bt) (90W per port):	Not supported

Compatible Expansion Cards

Not supported

S2300-EI Datasheet (en)
