Switches Huawei S2700-EI Series
Switches Huawei S2700-EI Series
End-of-Sale

Please see "Similar Products" below
Description Specifications Additional materials

Huawei S2700-EI Series Switches are used in Enterprise Networks.

S2700-EI switches provide flexible network deployment, and helps enterprise customers to create reliable and secure next-generation IT networks.

State-of-the-art switching technology and software from the Huawei Versatile Routing Platform (VRP) provides easy management, maintenance, comprehensive services and network access.

The S2700-EI models support the PoE/PoE + standard, which provides power up to 30 watts per port for supporting network devices such as telephones, camcorders, IEEE 802.11n wireless devices, and LAN access points (WLANs).

General All
Interfaces
1
S2700-9TP-EI-AC/DC:
  • 8-Port 10/100MbE (RJ45);
  • 1-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2700-9TP-PWR-EI:
  • 8-Port 10/100MbE (RJ45) PoE;
  • 1-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2700-18TP-EI-AC:
  • 16-Port 10/100MbE(RJ45);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2700-26TP-EI-AC/DC:
  • 24-Port 10/100MbE (RJ45);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2700-26TP-PWR-EI:
  • 24-Port 10/100MbE (RJ45) PoE;
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2700-52P-EI-AC:
  • 48-Port 10/100MbE (RJ45);
  • 4-Port 1GbE (SFP);
  • 1-Port console (RJ45)
S2700-52P-PWR-EI:
  • 48-Port 10/100MbE (RJ45) PoE;
  • 4-Port 1GbE (SFP);
  • 1-Port console (RJ45)
S2750-28TP-EI-AC:
  • 24-Port 10/100MbE(RJ45);
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2750-20TP-PWR-EI-AC:
  • 16-Port 10/100MbE(RJ45) PoE;
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2750-28TP-PWR-EI-AC:
  • 24-Port 10/100MbE (RJ45) PoE;
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2751-28TP-PWR-EI-AC:
  • 24-Port 10/100MbE (RJ45) PoE;
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S2720-28TP-EI-AC:
  • 24-Port 10/100MbE (RJ45);
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
S2700-9TP-EI-AC/DC:
43.6 (1U) х 250 х 180
(1.72 (1U) x 9.84 x 7.09 in)
S2700-9TP-PWR-EI:
43.6 (1U) х 320 х 220
(1.72 (1U) x 12.59 x 8.66 in)
S2700-18TP-EI-AC:
S2700-26TP-EI-AC/DC:
S2750-28TP-EI-AC:
S2720-28TP-EI-AC:
S2700-52P-EI-AC:
43.6 (1U) х 442 x 220
(1.72 (1U) x 17.4 x 8.66 in)
S2750-20TP-PWR-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
43.6 (1U) х 442 х 310
(1.72 (1U) x 17.4 x 12.20 in)
4
Maximum Weight (kg)
S2700-9TP-EI-AC/DC: 1.4 (3.09 lbs)
S2700-9TP-PWR-EI: 2.5 (5.5 lbs)
S2700-18TP-EI-AC:
S2700-26TP-EI-AC/DC:
 2.4 (5.3 lbs)
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
S2750-20TP-PWR-EI:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:

4.5 (9.92 lbs)
S2700-52P-EI-AC:
S2720-28TP-EI-AC:
S2750-28TP-EI-AC:
 3.0 (6.61 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

-5 to +50 (23 to 122 °F)

8
Maximum Power Consumption (W)
S2700-9TP-EI-AC/DC:
12.8
S2700-9TP-PWR-EI:
154.0
S2700-18TP-EI-AC:
14.5
S2700-26TP-EI-AC/DC:
15.5
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
808.0
S2700-52P-EI-AC:
38.0
S2750-20TP-PWR-EI-AC:
435.0
S2750-28TP-EI-AC:
15.7
S2750-28TP-PWR-EI-AC:
445.0
S2751-28TP-PWR-EI-AC:
147.0
S2720-28TP-EI-AC:
15.7
9
Acoustic noise (dB)
S2700-9TP-EI-AC/DC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC/DC:
S2700-52P-EI-AC:
S2750-28TP-EI-AC:
S2751-28TP-PWR-EI-AC:
S2720-28TP-EI-AC:
 0
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
S2750-20TP-PWR-EI-AC:
S2750-28TP-PWR-EI-AC:
 52
10
Performance
11
Switching Bandwidth (Gbit/s)
S2700-9TP-EI-AC/DC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC/DC:
S2700-26TP-PWR-EI:
S2700-52P-EI-AC:
S2700-52P-PWR-EI:
 32
S2750-20TP-PWR-EI-AC:
S2750-28TP-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
 64
S2720-28TP-EI-AC: 12.8
12
Forwarding Rate (Mp/s)
S2700-9TP-EI-AC/DC:
S2700-9TP-PWR-EI:
 2.7
S2700-18TP-EI-AC: 5.4
S2700-26TP-EI-AC/DC:
S2700-26TP-PWR-EI:
 6.6
S2700-52P-EI-AC:
S2700-52P-PWR-EI:
 13.2
S2750-20TP-PWR-EI-AC: 8.4
S2750-28TP-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
S2720-28TP-EI-AC:
 9.6
13
MAC Address Table (entries)
S2700-9TP-EI-AC:
S2700-9TP-EI-DC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC:
S2700-26TP-EI-DC:
S2700-26TP-PWR-EI:
S2700-52P-EI-AC:
S2700-52P-PWR-EI:
 8000
S2750-28TP-EI-AC:
S2720-28TP-EI-AC:
S2750-20TP-PWR-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
 16,000



14
ARP Table (entries)

256

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability
S2700-9TP-EI-AC:
S2700-9TP-EI-DC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC:
S2700-26TP-EI-DC:
S2700-26TP-PWR-EI:
S2700-52P-EI-AC:
S2700-52P-PWR-EI:
 STP/RSTP/MSTP; RRPP
S2750-28TP-EI-AC:
S2720-28TP-EI-AC:
S2750-20TP-PWR-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
 STP/RSTP/MSTP; RRPP; ERPS (G.8032)
18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 512
Multicast VLAN (MVR): Supported
Multicast Routing: Not supported
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 16
IPv6: 16
22
IP Routing

Static Routing

23
MPLS / VPN
24

Not supported

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Not supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type:
S2700-9TP-EI-AC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC:
S2700-52P-EI-AC:
S2750-20TP-PWR-EI-AC:
S2750-28TP-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
S2720-28TP-EI-AC:		 Built-in
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
 Removable
Quantity:
S2700-9TP-EI-AC:
S2700-9TP-PWR-EI:
S2700-18TP-EI-AC:
S2700-26TP-EI-AC:
S2700-52P-EI-AC:
S2750-20TP-PWR-EI-AC:
S2750-28TP-EI-AC:
S2750-28TP-PWR-EI-AC:
S2751-28TP-PWR-EI-AC:
S2720-28TP-EI-AC:
 1
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
 2
Rated voltage range:  100 to 240 VAC, 50-60 Hz
31
DC PSU
Type:

S2700-9TP-EI-DC:
S2700-26TP-EI-DC:
 Built-in
Quantity: 1
Rated voltage range:  -48 to -60 VDC
32
PoE (Power over Ethernet)
33
Supported by:
S2700-9TP-PWR-EI;
S2700-26TP-PWR-EI;
S2700-52P-PWR-EI;
S2750-20TP-PWR-EI-AC;
S2750-28TP-PWR-EI-AC;
S2751-28TP-PWR-EI-AC
PoE (802.3af) (15W per port):
S2700-9TP-PWR-EI:
S2751-28TP-PWR-EI-AC:
 8 ports
S2700-26TP-PWR-EI: 24 ports (with 500W PSU)
S2700-52P-PWR-EI: 48 ports (with 2 x 500W PSU)
S2750-20TP-PWR-EI-AC: 16 ports
S2750-28TP-PWR-EI-AC: 24 ports

PoE+ (802.3аt) (30W per port):
S2700-9TP-PWR-EI:
S2751-28TP-PWR-EI-AC:
 4 ports
S2700-26TP-PWR-EI:
S2700-52P-PWR-EI:
 24 ports (with 2 x 500W PSU)
S2750-20TP-PWR-EI-AC:
S2750-28TP-PWR-EI-AC:
 12 ports

PoE++ (802.3bt) (60W per port): Not supported

PoE++ (802.3bt) (90W per port): Not supported
34
Compatible Expansion Cards
35

Not supported

36

S2700-EI Datasheet (en)
