Switches Huawei S3700TP-SI Series

End-of-Sale

Please see "Similar Products" below.

Description Specifications Additional materials

Huawei S3700TP-SI Series Layer 3 Managed Switches provide flexible switching, PoE support, IPv6 support, and enable corporate customers to create next-generation IT networks.

General All

Интерфейсы

S3700-28TP-SI-AC:	24-Port 10/100MbE (RJ45); 2-Port 1GbE (SFP); 2-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S3700-28TP-PWR-SI:	24-Port 10/100MbE (RJ45) PoE; 2-Port 1GbE (SFP); 2-Port combo 1GbE (RJ45/SFP); 1-Port console (RJ45)
S3700-52P-SI-AC:	48-Port 10/100MbE (RJ45); 2-Port 100/1000MbE (SFP); 2-Port 1GbE (SFP); 1-Port console (RJ45)
S3700-52P-PWR-SI:	48-Port 10/100MbE (RJ45) PoE; 2-Port 100/1000MbE (SFP); 2-Port 1GbE (SFP); 1-Port console (RJ45)

Physical Parameters

Dimensions (HxWxD) (mm)

S3700-28TP-SI-AC: S3700-28TP-PWR-SI:	43.6 (1U) x 442 x 220 (1.72 (1U) x 17.4 x 8.66 in)
S3700-28TP-PWR-SI: S3700-52P-PWR-SI:	43.6 (1U) х 442 х 420 (1.72 (1U) x 17.4 x 16.54 in)

Maximum Weight (kg)

S3700-28TP-SI-AC:	2.5 (5.51 lbs)
S3700-28TP-PWR-SI:	4.0 (8.81 lbs)
S3700-52P-SI-AC:	3.0 (6.61 Ib)
S3700-52P-PWR-SI:	4.3 (9.41 Ib)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)

0 to 50 (32 to 122 °F)

Maximum Power Consumption (W)

S3700-28TP-SI-AC:	20
S3700-28TP-PWR-SI:	818
S3700-52P-SI-AC:	38
S3700-52P-PWR-SI:	880

Acoustic noise (dB)

S3700-28TP-SI-AC:	0
S3700-28TP-PWR-SI: S3700-52P-SI-AC: S3700-52P-PWR-SI:	52

Performance

Switching Bandwidth (Gbit/s)

Forwarding Rate (Mp/s)

S3700-28TP-SI-AC: S3700-28TP-PWR-SI:	9.6
S3700-52P-SI-AC: S3700-52P-PWR-SI:	13.2

MAC Address Table (entries)

16,000

ARP Table (entries)

2048

Layer 2 Features

VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP, RRPP

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	1024
Multicast VLAN (MVR):	Supported
Multicast Routing:	Not supported

Layer 3 Features

Routing Table (routes)

IPv4:	8000
IPv6:	4000

IP Routing

Static Routing; RIPv1/2

MPLS / VPN

Not supported

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

Power Supply Unit (PSU)

AC PSU

Type:
S3700-28TP-SI-AC: S3700-52P-SI-AC:	Built-in
S3700-28TP-PWR-SI: S3700-52P-PWR-SI:	Removable
Quantity:
S3700-28TP-SI-AC: S3700-28TP-PWR-SI: S3700-52P-SI-AC:	1
S3700-52P-PWR-SI:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:
S3700-28TP-PWR-SI: S3700-52P-PWR-SI:	Removable
Quantity:
S3700-28TP-PWR-SI: S3700-52P-PWR-SI:	2
Rated voltage range:	-48 to -60 VDC

PoE (Power over Ethernet)

Supported by:	S3700-28TP-PWR-SI; S3700-52P-PWR-SI

PoE (802.3af) (15W per port):
S3700-28TP-PWR-SI:	24 ports (with 500 W PSU)
S3700-52P-PWR-SI:	24 ports (with 2 x 500 W PSU)

PoE+ (802.3аt) (30W per port):
S3700-28TP-PWR-SI: S3700-52P-PWR-SI:	24 ports (with 2 x 500 W PSU)

PoE++ (802.3bt) (60W per port):	Not supported

PoE++ (802.3bt) (90W per port):	Not supported

Compatible Expansion Cards

Not supported

S3700-SI Datasheet (en)
