Switches Huawei S5720-LI Series Available to Quote:
S5720-12TP-LI-AC; S5720-12TP-PWR-LI-AC;
S5720-28P-LI-AC; S5720-28P-PWR-LI-AC;
S5720-52P-LI-AC; S5720-52P-PWR-LI-AC;
S5720-28TP-LI-ACL; S5720-28TP-PWR-LI-AC;
S5720-28TP-PWR-LI-ACL
Request a Quote
Description Specifications Additional materials

Huawei S5720-LI series gigabit switches with fixed ports of 1GbE access are designed for office infrastructure and large campus networks.

General All
Interfaces
1
S5720-12TP-LI-ACI:
  • 8-Port 1GbE (RJ45);
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S5720-12TP-PWR-LI-AC:
  • 8-Port 1GbE (RJ45) PoE;
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S5720-28P-LI-AC:
  • 24-Port 1GbE (RJ45);
  • 4-Port 1/10GbE (SFP) (with license to activate 10G capability);
  • 1-Port console (RJ45);
  • 1-Port RPS
S5720-28P-PWR-LI-AC:
  • 24-Port 1GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP) (with license to activate 10G capability);
  • 1-Port console (RJ45);
  • 1-Port RPS
S5720-28TP-LI-AC:
  • 24-Port 1GbE (RJ45);
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)
S5720-28TP-PWR-LI-AC:
  • 24-Port 1GbE (RJ45) PoE;
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S5720-28TP-PWR-LI-ACL:
  • 8-Port 1GbE (RJ45) PoE;
  • 16-Port 1GbE (RJ45);
  • 2-Port 1GbE (SFP);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port console (RJ45)
S5720-52P-LI-AC:
  • 48-Port 1GbE (RJ45);
  • 4-Port 1/10GbE (SFP) (with license to activate 10G capability);
  • 1-Port console (RJ45);
  • 1-Port RPS
S5720-52P-PWR-LI-AC:
  • 48-Port 1GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP) (with license to activate 10G capability);
  • 1-Port console (RJ45);
  • 1-Port RPS
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
S5720-12TP-LI-AC:
43.6 (1U) х 250 х 180
(1.72 (1U) x 9.84 x 7.1 in)
S5720-12TP-PWR-LI-AC:
43.6 (1U) х 320 х 220
(1.72 (1U) x 12.6 x 8.7 in)
S5720-28P-LI-AC:
S5720-28TP-LI-AC:
S5720-28TP-PWR-LI-ACL:
S5720-52P-LI-AC:
43.6 (1U) x 442 x 220
(1.72 (1U) x 17.4 x 8.7 in)
S5720-28P-PWR-LI-AC:
S5720-28TP-PWR-LI-AC:
S5720-52P-PWR-LI-AC:
43.6 (1U) x 442 x 310
(1.72 (1U) x 17.4 x 12.2 in)
4
Maximum Weight (kg)
S5720-12TP-LI-AC: 1.8 (3.97 lbs)
S5720-12TP-PWR-LI-AC: 3.0 (6.62 lbs)
S5720-28P-LI-AC: 3.9 (8.6 lbs)
S5720-28P-PWR-LI-AC: 5.2 (11.45 lbs)
S5720-28TP-LI-AC: 4.0 (8.82 lbs)
S5720-28TP-PWR-LI-AC: 5.3 (11.69 lbs)
S5720-28TP-PWR-LI-ACL: 4.5 (9.92 lbs)
S5720-52P-LI-AC: 4.4 (9.7 lbs)
S5720-52P-PWR-LI-AC: 5.6 (12.35 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 45 (32 to 113 °F)

8
Maximum Power Consumption (W)
S5720-12TP-LI-ACI: 12.85
S5720-12TP-PWR-LI-AC: 160.5
S5720-28P-LI-AC: 27.9
S5720-28P-PWR-LI-AC: 448.5
S5720-28TP-LI-AC: 22.1
S5720-28TP-PWR-LI-AC: 444.8
S5720-28TP-PWR-LI-ACL: 165.6
S5720-52P-LI-AC: 50.3
S5720-52P-PWR-LI-AC: 464.3
9
Acoustic noise (dB)
S5720-12TP-LI-AC:
S5720-12TP-PWR-LI-AC:
S5720-28P-LI-AC:
S5720-28TP-LI-AC:
S5720-28TP-PWR-LI-ACL:
0
S5720-28P-PWR-LI-AC: 49.1
S5720-28TP-PWR-LI-AC: 48.6
S5720-52P-LI-AC: 44.5
S5720-52P-PWR-LI-AC: 48.3
10
Performance
11
Switching Bandwidth (Gbit/s)

336

12
Forwarding Rate (Mp/s)
S5720-12TP-LI-AC:
S5720-12TP-PWR-LI-AC:
27
S5720-28P-LI-AC:
S5720-28P-PWR-LI-AC:
S5720-28TP-LI-AC:
S5720-28TP-PWR-LI-AC:
S5720-28TP-PWR-LI-ACL:
51
S5720-52P-LI-AC:
S5720-52P-PWR-LI-AC:
87
13
MAC Address Table (entries)

16,000

14
ARP Table (entries)

2048

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; ERPS (G.8032); SEP

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 1024
Multicast VLAN (MVR): Supported
Multicast Routing: Not supported
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 4000
IPv6: 1000
22
IP Routing

Static Routing; RIP; OSPF

23
MPLS / VPN
24

Not supported

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type: Built-in
Quantity: 1
Rated voltage range: 100 to 240 VAC, 50-60 Hz
31
DC PSU

Not supported

32
PoE (Power over Ethernet)
33
Supported by:
S5720-12TP-PWR-LI-AC;
S5720-28P-PWR-LI-AC;
S5720-28TP-PWR-LI-AC;
S5720-28TP-PWR-LI-ACL;
S5720-52P-PWR-LI-AC
PoE (802.3af) (15W per port):
S5720-12TP-PWR-LI-AC:
S5720-28TP-PWR-LI-ACL:
8 ports
S5720-28P-PWR-LI-AC:
S5720-28TP-PWR-LI-AC:
S5720-52P-PWR-LI-AC:
24 ports

PoE+ (802.3аt) (30W per port):
S5720-12TP-PWR-LI-AC:
S5720-52P-PWR-LI-AC:
4 ports
S5720-28P-PWR-LI-AC:
S5720-28TP-PWR-LI-AC:
S5720-28TP-PWR-LI-ACL:
12 ports

PoE++ (802.3bt) (60W per port):
Not supported

PoE++ (802.3bt) (90W per port): Not supported
34
Compatible Expansion Cards
35

Not supported
