Switches Huawei S5720-SI Series
Switches Huawei S5720-SI Series Available to Quote:
S5720-14X-PWH-SI-AC; S5720-28P-SI-AC
S5720-52P-SI-AC; S5720-28X-SI-AC
S5720-28X-SI-DC; S5720-28X-PWR-SI-AC
S5720-28X-PWR-SI-DC; S5720-28X-SI-24S-AC
S5720-28X-SI-24S-DC; S5720-52X-SI-AC
S5720-52X-SI-DC; S5720-52X-PWR-SI-AC
S5720-52X-PWR-SI-DC; S5720-52X-PWR-SI-ACF
S5721-28X-SI-24S-AC
 Request a Quote
Description Specifications Additional materials

Huawei S5720-SI Series Gigabit Switches with 10 GbE Flexible Fixed Ports are designed for data centers and campus networks

General All
Interfaces
1
S5720-14X-PWH-SI-AC:
  • 8-Port 1GbE (RJ45) PoE;
  • 4-Port 100MbE/1GbE/2.5GbE (RJ45) PoE;
  • 2-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-28P-SI-AC:
  • 24-Port 1GbE (RJ45);
  • 4-Port combo 1GbE (RJ45/SFP);
  • 4-Port 1GbE (SFP);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-52P-SI-AC:
  • 48-Port 1GbE (RJ45);
  • 4-Port 1GbE (SFP);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-28X-SI-AC/-DC:
  • 20-Port 1GbE (RJ45);
  • 4-Port combo 1GbE (RJ45/SFP);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-28X-PWR-SI-AC/-DC:
  • 20-Port 1GbE (RJ45) PoE;
  • 4-Port combo 1GbE (RJ45/SFP);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-28X-SI-24S-AC/-DC:
  • 16-Port 100/1000MbE (SFP);
  • 8-Port combo 1GbE (RJ45/SFP);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB;
  • 1-Port RPS
S5720-52X-SI-AC/-DC:
  • 48-Port 1GbE (RJ45);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-52X-PWR-SI-AC/-DC:
  • 48-Port 1GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5720-52X-PWR-SI-ACF:
  • 48-Port 1GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
S5721-28X-SI-24S-AC
  • 16-Port 100/1000MbE (SFP);
  • 8-Port combo 1GbE (RJ45/SFP);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
S5720-14X-PWH-SI-AC:
43.6 (1U) x 442 x 310
(1.69 (1U) x 17.40 x 12.20 in)
S5720-28P-SI-AC:
S5720-28X-SI-AC/-DC:
S5720-28X-PWR-SI-AC/-DC:
S5720-52P-SI-AC:
S5720-52X-PWR-SI-AC/-DC:
S5720-52X-SI-AC/-DC:
S5721-28X-SI-24S-AC:
44.4 (1U) x 442 x 420
(1.74 (1U) x 17.40 x 16.53 in)
S5720-28X-SI-24S-AC/-DC:
43.6 (1U) x 442 x 220
(1.71 (1U) x 17.40 x 8.66 in)
S5720-52X-PWR-SI-ACF:
44.4 (1U) x 442 x 507
(1.74 (1U) x 17.40 x 19.96 in)
4
Maximum Weight (kg)
S5720-14X-PWH-SI-AC: 5.9 (13.01 lbs)
S5720-28P-SI-AC:
S5720-28X-SI-AC/-DC:
 9.1 (20.06 lbs)
S5720-52P-SI-AC:
S5720-52X-SI-AC/-DC:
 9.5 (20.95 lbs)
S5720-28X-PWR-SI-AC/-DC: 9.3 (20.51 lbs)
S5720-28X-SI-24S-AC/-DC:
 4.1 (9.04 lbs)
S5720-52X-PWR-SI-AC/-DC: 9.6 (21.17 lbs)
S5720-52X-PWR-SI-ACF:
 10.0 (22.05 lbs)
S5721-28X-SI-24S-AC:
 8.6 (18.96 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
S5720-14X-PWH-SI-AC: 422.0
S5720-28P-SI-AC:
 34.6
S5720-52P-SI-AC:
 53.6
S5720-28X-SI-AC:
 37.5
S5720-28X-SI-DC:
 36.9
S5720-28X-PWR-SI-AC: 913.0
S5720-28X-PWR-SI-DC: 887.0
S5720-28X-SI-24S-AC:
 41.7
S5720-28X-SI-24S-DC:
 42.7
S5720-52X-SI-AC:
 56.8
S5720-52X-SI-DC:
 57.9
S5720-52X-PWR-SI-AC/-DC: 943.2
S5720-52X-PWR-SI-ACF:
 1631.5
S5721-28X-SI-24S-AC:
 41.0
9
Acoustic noise (dB)
S5720-14X-PWH-SI-AC:
S5720-28P-SI-AC:
S5720-52P-SI-AC:
S5720-28X-SI-AC:
S5720-28X-SI-DC:
S5720-52X-SI-AC:
S5720-52X-SI-DC:
 52.0
S5720-28X-PWR-SI-AC:
S5720-28X-PWR-SI-DC:
S5720-52X-PWR-SI-AC/-DC:
S5720-52X-PWR-SI-ACF:
 56.5
S5720-28X-SI-24S-AC:
S5720-28X-SI-24S-DC:
 43.0
S5721-28X-SI-24S-AC:
 50.3
10
Performance
11
Switching Bandwidth (Gbit/s)

336

12
Forwarding Rate (Mp/s)

S5720-14X-PWH-SI-AC:

S5720-28P-SI-AC:

 42
S5720-52P-SI-AC: 78
S5720-28X-SI-AC/-DC:
S5720-28X-PWR-SI-AC/-DC:
S5720-28X-SI-24S-AC/-DC:
S5721-28X-SI-24S-AC:
 96
S5720-52X-PWR-SI-AC/-DC:
S5720-52X-SI-AC/-DC:
S5720-52X-PWR-SI-ACF:
 132
13
MAC Address Table (entries)

16,000

14
ARP Table (entries)

2048

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094.  GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; SEP; RRPP; ERPS (G.8032)

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 1024
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-DM, PIM-SM, PIM-SSM
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 8000
IPv6: 1000
22
IP Routing

Static Routing; RIP; OSPF; IS-IS; BGP

23
MPLS / VPN
24

Not supported

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type:
S5720-14X-PWH-SI-AC:
S5720-28X-SI-24S-AC:
 Built-in
Quantity:

S5720-14X-PWH-SI-AC:
S5720-28X-SI-24S-AC:
 1
S5720-28P-SI-AC:
S5720-52P-SI-AC:
S5720-28X-SI-AC
S5720-28X-PWR-SI-AC:
S5720-52X-SI-AC:
S5720-52X-PWR-SI-AC:
S5720-52X-PWR-SI-ACF:
S5721-28X-SI-24S-AC:
  2
Rated voltage range: 100 to 240 VAC, 50-60 Hz
31
DC PSU
Type:
S5720-28X-SI-DC:
S5720-28X-PWR-SI-DC:
S5720-28X-SI-24S-DC:
S5720-52X-SI-DC:
S5720-52X-PWR-SI-DC:
S5721-28X-SI-24S-AC:
 Removable
Quantity: 2
Rated voltage range: -36 to -72 VDC
32
PoE (Power over Ethernet)
33
Supported by:
S5720-14X-PWH-SI-AC;
S5720-28X-PWR-SI-AC/-DC;
S5720-52X-PWR-SI-AC/-DC;
S5720-52X-PWR-SI-ACF
PoE (802.3af) (15W per port):
S5720-14X-PWH-SI-AC: 12 ports
S5720-28X-PWR-SI-AC/-DC: 24 ports
S5720-52X-PWR-SI-AC/-DC:
 48 ports (with 2 x 500W PSU)
S5720-52X-PWR-SI-ACF:
 48 ports (with 2 x 1150W PSU)

PoE+ (802.3аt) (30W per port):
S5720-14X-PWH-SI-AC: 12 ports
S5720-28X-PWR-SI-AC/-DC:
S5720-52X-PWR-SI-AC/-DC:
 24 ports (with 2 x 500W PSU)
S5720-52X-PWR-SIACF:
 48 ports (with 2 x 1150W PSU)

PoE++ (802.3bt) (60W per port):
S5720-14X-PWH-SI-AC: 4 ports

PoE++ (802.3bt) (90W per port):
S5720-14X-PWH-SI-AC: 4 ports
34
Compatible Expansion Cards
35

Not supported

36

S5720-SI Datasheet (en)
