Huawei S5735-S series switches with fixed 1GbE ports.

General All

Interfaces

S5735-S24T4X:	24-Port 1GbE (RJ45); 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1-Port USB
S5735-S24P4X:	24-Port 1GbE (RJ45) PoE+; 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1 порт USB
S5735-S48T4X:	24-Port 1GbE (RJ45) PoE; 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1-Port USB
S5735-S48P4X:	48-Port 1GbE (RJ45) PoE+; 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1-Port USB
S5735-S48S4X:	48-Port 1GbE (SFP); 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1-Port USB
S5735-S32ST4X:	24-Port 1GbE (SFP); 8-Port 1GbE (RJ45); 4-Port 10GbE (SFP+); 1-Port console (RJ45); 1-Port out-of-band management 10/100MbE (RJ45); 1-Port USB

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

44.4 (1U) x 442 x 420

(1.72 (1U) x 17.4 x 16.53)

Maximum Weight (kg)/(lbs)

S5735-S24T4X:	7.21 (15.89)
S5735-S24P4X:	7.39 (16.29)
S5735-S48T4X:	7.64 (16.84)
S5735-S48P4X:	8.27 (18.23)
S5735-S48S4X:	7.69 (16.95)
S5735-S32ST4X:	7.47 (16.46)

Environmental Conditions

Relative Humidity (%)

5 to 95

Operating Temperature (°C)/(°F)

-5 to 45 (23 to 113)

Maximum Power Consumption (W)

S5735-S24T4X:	46
S5735-S24P4X:	847
S5735-S48T4X:	59
S5735-S48P4X:	1661
S5735-S48S4X:	89
S5735-S32ST4X:	66

Acoustic noise (dB)

S5735-S24T4X: S5735-S24P4X: S5735-S48T4X: S5735-S48P4X:	58,9
S5735-S48S4X:	61,0
S5735-S32ST4X:	59,3

Performance

Switching Bandwidth (Gbit/s)

S5735-S24T4X: S5735-S24P4X:	128
S5735-S48T4X: S5735-S48P4X: S5735-S48S4X:	176
S5735-S32ST4X:	144

Forwarding Rate (Mp/s)

S5735-S24T4X: S5735-S24P4X:	96
S5735-S48T4X: S5735-S48P4X: S5735-S48S4X:	132
S5735-S32ST4X:	108

MAC Address Table (entries)

16,512

ARP Table (entries)

8000

Layer 2 Features

VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP; VBST (PVST+); SEP; RRPP; ERPS (G.8032)

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	1500
Multicast VLAN (MVR):	Supported
Multicast Routing:	PIM-DM; PIM-SM; MSDP

Layer 3 Features

Routing Table (routes)

IPv4:	8192
IPv6:	3072

IP Routing

Static Routing; RIPv1/2; OSPF

MPLS / VPN

Not supported

VXLAN

Not supported

Безопасность

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop Detection:	Supported
IP Source Guard:	Supported
Bandwidth Limitation:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-48 to -60 VDC

PoE (Power over Ethernet)

Supported by:	S5735-S24P4X; S5735-S48P4X

PoE (802.3af) (15W per port):
S5735-S24P4X:	24 ports
S5735-S48P4X:	48 ports

PoE+ (802.3аt) (30W per port):
S5735-S24P4X:	24 ports (with 2 x 1000W PSU)
S5735-S48P4X:	48 ports (with 2 x 1000W PSU)

PoE++ (802.3bt) (60W per port):	Not supported

PoE++ (802.3bt) (90W per port):	Not supported

Compatible Expansion Cards

Not supported
