Switches Huawei S6300-EI Series
Switches Huawei S6300-EI Series

End-of-Sale

Please see "Similar Products" below.
Description Specifications Additional materials

Huawei S6300-EI Series Switches with 10G Ports.

General All
Interfaces
1
S6324-EI:
  • 24-Port 1/10GbE (SFP)/(SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB;
  • 1-Port console (RJ45)
S6348-EI:
  • 48-Port 1/10GbE (SFP)/(SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port USB;
  • 1-Port console (RJ45)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
43.6 (1U) х 442 х 420
(1.72 (1U) x 17.4 x 16.54 in)
4
Maximum Weight (kg)

8.5 (18.7 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 45 (32 to 113°F)

8
Maximum Power Consumption (W)
S6324-EI: 153.6
S6348-EI: 240.0
9
Acoustic noise (dB)

55

10
Performance
11
Switching Bandwidth (Gbit/s)
S6324-EI: 480
S6348-EI: 960
12
Forwarding Rate (Mp/s)
S6324-EI: 357.0
S6348-EI: 714.2
13
MAC Address Table (entries)

128,000

14
ARP Table (entries)

8000

15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; VBST; SEP; RRPP; ERPS (G.8032)

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 2048
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-DM; PIM-SM; PIM-SSM
20
Layer 3 Features
21
Routing Table (routes)
IPv4: 16,000
IPv6: 8000
22
IP Routing

Static Routing; RIPv1/2; OSPFv2; IS-IS; BGP; VRRP

23
MPLS / VPN
24

MPLS, L2VPN, L3VPN, VPLS, GRE

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz
31
DC PSU
Type: Removable
Quantity: 2
Rated voltage range: -48 to -60 VDC
32
PoE (Power over Ethernet)
33

Not supported

34
Compatible Expansion Cards
35

Not supported

36

S6300-EI Datasheet (en)
