Gigabit switches of the Huawei S6720-HI series, with flexible fixed access ports 10GbE, 40GbE, 100GbE, are designed for large campus, corporate and transport enterprises.
State-of-the-art hardware and the versatile Huawei VRP routing platform provide easy management, maintenance, security and data protection on the network.
The switches support Unified Virtual Fabric technology to create a virtual network of any size, including mobile services, video services and collaboration services for employees.
| S6720-50L-HI-48S: |
|
| S6720-30L-HI-24S: |
|
|
S6720-50L-HI-48S: |
9.86 (21.74 lbs) |
| S6720-30L-HI-24S: | 10.16 (22.39 lbs) |
5 to 95
0 to 45 (32 to 113 °F)
|
S6720-50L-HI-48S: |
279 |
| S6720-30L-HI-24S: | 232 |
65
2.56
420
64,000
IEEE 802.1Q: 4094. GVRP; QinQ; VLAN Translation
STP/RSTP/MSTP; SEP; RRPP; ERPS (G.8032)
| IGMP snooping: | v1/v2/v3 |
| IGMP groups: | 4096 |
| Multicast VLAN (MVR): | Supported |
| Multicast Routing: | PIM-SM, PIM-DM, PIM-SSM, MSDP |
| IPv4: | 64,000 |
| IPv6: | 22,000 |
Static Routing; RIPv1/v2; OSPF, IS-IS; BGP
Supported. MPLS LDP, L2VPN, L3VPN, VPLS
| Local AAA: | Supported |
| RADIUS, TACACS+: | Supported |
| DHCP Server: | Supported |
| DHCP Relay option82: | Supported |
| DHCP Snooping: | Supported |
| Loop detection: | Supported |
| IP Source Guard: | Supported |
| Bandwidth Limit: | Supported |
| Broadcast, multicast, unknown unicast suppression: | Supported |
Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP
| Type: | Removable |
| Quantity: | 2 |
| Rated voltage range: | 100 to 240 VAC, 50-60 Hz |
| Type: | Removable |
| Quantity: | 2 |
| Rated voltage range: | -48 to 60 VDC |
Not supported
Not supported
