The next-generation, high-density, S6720-LI Series Switches are good for data centers, service providers, and large campus networks.
Models in a compact 1U form factor with fixed access ports - 16-port 1/10GbE (SFP/SFP+), 32-port 1/10GbE (SFP/SFP+), or 24-port 1/10GbE (SFP/SFP+) and 2-port 40GbE (QSFP+).
|
S6720-16X-LI-16S-AC:
|
|
|
S6720-32X-LI-32S-AC:
|
|
|
S6720-26Q-LI-24S-AC:
|
|
| S6720-16X-LI-16S-AC: | 4.1 (9.04 lbs) |
| S6720-26Q-LI-24S-AC: | 4.3 (9.48 lbs) |
| S6720-32X-LI-32S-AC: | 4.2 (9.26 lbs) |
5 to 95
0 to 45 (32 to 113 °F)
| S6720-16X-LI-16S-AC: | 67.9 |
| S6720-26Q-LI-24S-AC: | 108.5 |
| S6720-32X-LI-32S-AC: | 100.2 |
46.5
1.28
240
32,000
IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation
STP/RSTP/MSTP; SEP; RRPP; ERPS (G.8032)
| IGMP snooping: | v1/v2/v3 |
| IGMP groups: | 1024 |
| Multicast VLAN (MVR): | Supported |
| Multicast Routing: | Not supported |
Static Routing; RIP; OSPF
Not supported
| Local AAA: | Supported |
| RADIUS, TACACS+: | Supported |
| DHCP Server: | Supported |
| DHCP Relay option82: | Supported |
| DHCP Snooping: | Supported |
| Loop detection: | Supported |
| IP Source Guard: | Supported |
| Bandwidth Limit: | Supported |
| Broadcast, multicast, unknown unicast suppression: | Supported |
Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP
| Type: | Built-in |
| Quantity: | 1 |
| Rated voltage range: | 100 to 240 VAC, 50-60 Hz |
Not supported
Not supported
Not supported
