Switches Huawei S6720-SI Series
Switches Huawei S6720-SI Series
End-of-Sale

Please see "Similar Products" below


Description Specifications Additional materials

Huawei S6720-SI Series Switches with 1GbE and 10GbE fixed ports provide high-speed connectivity to wireless access points and servers at 10GbE speeds, perfect for service providers and large campus networks.

The S6720-SI switches provide advanced switching technologies and comprehensive QoS policies to help their customers build a scalable, manageable, secure and reliable network.

General All
Interfaces
1
S6720-26Q-SI-24S-AC:
  • 24-Port 1/10GbE (SFP/SFP+);
  • 2-Port 40GbE (QSFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB
S6720-32X-SI-32S-AC:
  • 32-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB
S6720-32C-SI-AC/DC:
  • 24-Port 100MbE/1GbE/2.5GbE/5GbE/10GbE (RJ45);
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1 Expansion slot
S6720-32C-PWH-SI-AC:
  • 24-Port 100MbE/1GbE/2.5GbE/10GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1 Expansion slot
S6720-32C-PWH-SI:
  • 24-Port 100MbE/1GbE/2.5GbE/5GbE/10GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1 Expansion slot
S6720-56C-PWH-SI-AC:
  • 32-Port 1GbE (RJ45) PoE;
  • 16-Port 100MbE/1GbE/2.5GbE/5GbE/10GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1 Expansion slot
S6720-56C-PWH-SI:
  • 32-Port 1GbE (RJ45) PoE;
  • 16-Port 100MbE/1GbE/2.5GbE/5GbE/10GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB;
  • 1 Expansion slot
S6720-52X-PWH-SI:
  • 48-Port 100MbE/1GbE/2.5GbE/5GbE/10GbE (RJ45) PoE;
  • 4-Port 1/10GbE (SFP/SFP+);
  • 1-Port out-of-band management 10/100MbE (RJ45);
  • 1-Port console (RJ45);
  • 1-Port USB



2
Physical Parameters
3
Dimensions (HxWxD) (mm)/(in)
44.4 (1U) x 442 x 420
(1.74 (1U) х 17.40 х 16.53)
4
Maximum Weight (kg)/(lbs)
S6720-26Q-SI-24S-AC:
S6720-32X-SI-32S-AC:
 8.9 (19.62)
S6720-32C-SI-AC/DC: 8.7 (19.18)

S6720-32C-PWH-SI-AC:

 9.1 (20.06)

S6720-32C-PWH-SI:

 8.1 (17.86)

S6720-56C-PWH-SI-AC:

 9.3 (20.5)

S6720-56C-PWH-SI:

 8.3 (18.29)

S6720-52X-PWH-SI:

 7.0 (15.43)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)/(°F)

0 to 45 (32 to 113)

8
Maximum Power Consumption (W)
S6720-26Q-SI-24S-AC:
97.0
S6720-32X-SI-32S-AC:
104.6
S6720-32C-SI-AC/DC:
117.62
S6720-32C-PWH-SI-AC:
1017.2
S6720-32C-PWH-SI:
1735.0
S6720-56C-PWH-SI-AC:
1068.1
S6720-56C-PWH-SI:
1995.4
S6720-52X-PWH-SI:
1724.4
9
Acoustic noise (dB)
S6720-26Q-SI-24S-AC:
57.0
S6720-32X-SI-32S-AC:
60.5
S6720-32C-SI-AC/DC:
S6720-32C-PWH-SI-AC:
S6720-32C-PWH-SI:
62.3
S6720-56C-PWH-SI-AC:
60.5
S6720-56C-PWH-SI:
62.1
S6720-52X-PWH-SI:
66.4
10
Performance
11
Switching Bandwidth (Tbit/s)

2.56

12
Forwarding Rate (Mp/s)

240

13
MAC Address Table (entries)

32,000

14
Layer 2 Features
15
VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

16
Layer 2 Reliability

STP/RSTP/MSTP; SEP; RRPP; ERPS (G.8032)

17
Multicast
18
IGMP snooping: v1/v2/v3
IGMP groups: 1024
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-SM; PIM-DP; MSDP
19
Layer 3 Features
20
IP Routing

Static Routing; RIPv1/v2; OSPF

21
MPLS / VPN
22

Not supported

23
Security
24
Local AAA: Supported
RADIUS, TACACS+: Supported
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
25
Management
26

Telnet; SSH; Web; LLDP; SNMP v1/v2/v3; RMON; Syslog; NTP

27
Power Supply Unit (PSU)
28
AC PSU
Type: Removable
Quantity: 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz
29
DC PSU
Type: Removable
Quantity: 2
Rated voltage range: -36 to -72 VDC
30
PoE (Power over Ethernet)
31
Supported by:
S6720-32C-PWH-SI-AC;
S6720-32C-PWH-SI;
S6720-56C-PWH-SI-AC;
S6720-56C-PWH-SI;
S6720-52X-PWH-SI;
PoE (802.3af) (15W per port):
S6720-32C-PWH-SI-AC:
S6720-32C-PWH-SI:
24 ports
S6720-56C-PWH-SI-AC:
S6720-56C-PWH-SI:
48 ports (with 2 x 650W PSU)
S6720-52X-PWH-SI:
48 ports (with 2 x 1150 W PSU)

PoE+ (802.3аt) (30W per port):
S6720-32C-PWH-SI-AC:
S6720-32C-PWH-SI:
24 ports (with 2 x 650W PSU)
S6720-56C-PWH-SI:
48 ports (with 2 x 1150 W PSU)
S6720-56C-PWH-SI-AC:
24 ports (with 2 x 650W PSU)
S6720-52X-PWH-SI:
48 ports (with 2 x 1150 W PSU)

PoE++ (802.3bt) (60W per port):
S6720-32C-PWH-SI-AC:
S6720-56C-PWH-SI-AC:
12 ports (with 2 x 650W PSU)
S6720-32C-PWH-SI:
S6720-56C-PWH-SI:
S6720-52X-PWH-SI:
24 ports (with 2 x 1150W PSU)

PoE++ (802.3bt) (90W per port)
Not supported
32
Compatible Expansion Cards
33
Model Number Description
Supported by:
S6720-32C-SI-AC/DC;
S6720-32C-PWH-SI-AC;
S6720-32C-PWH-SI;
S6720-56C-PWH-SI-AC;
S6720-56C-PWH-SI;
ES5D21Q02Q00: 2-Port 40GbE (QSFP+)
ES5D21X04S01: 4-Port 1/10GbE (SFP/SFP+)
34

S6720-SI Datasheet (en)
