Switches Juniper EX2200 Series

End-of-Sale

Please see "Similar Products" below.

Description Specifications Additional materials

The Juniper Networks EX2200 Series switches in a compact 1U form factor with 24 x 1GbE or 48 x 1GbE fixed ports

General All

Interfaces

EX2200-24T-4G:	24-Port 1GbE (RJ45); 4-Port 1GbE (SFP); 1-Port out-of-band management 1GbE (RJ45); 1-Port console (RJ45); 1-Port USB; 1-Port RPS
EX2200-24T-4G-DC:	24-Port 1GbE (RJ45); 4-Port 1GbE (SFP); 1-Port out-of-band management 1GbE (RJ45); 1-Port console (RJ45); 1-Port USB; 1-Port RPS
EX2200-48T-4G:	48-Port 1GbE (RJ45); 4-Port 1GbE (SFP); 1-Port out-of-band management 1GbE (RJ45); 1-Port console (RJ45); 1-Port USB; 1-Port RPS
EX2200-24P-4G:	24-Port 1GbE (RJ45) PoE; 4-Port 1GbE (SFP); 1-Port out-of-band management 1GbE (RJ45); 1-Port console (RJ45); 1-Port USB; 1-Port RPS.
EX2200-48P-4G:	48-Port 1GbE (RJ45) PoE; 4-Port 1GbE (SFP); 1-Port out-of-band management 1GbE (RJ45); 1-Port console (RJ45); 1-Port USB; 1-Port RPS.

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

44.6 (1U) x 441.0 х 254.3

(1.75 (1U) x 17.4 x 10.0)

Maximum Weight (kg)/(lbs)

EX2200-24T-4G: EX2200-24T-4G-DC:	2.7 (6.0)
EX2200-48T-4G: EX2200-24P-4G:	3.6 (8.0)
EX2200-48P-4G:	4.5 (10.0)

Environmental Conditions

Relative Humidity (%)

10 to 85

Operating Temperature (°C)/(°F)

0 to 45 (32 to 113)

Maximum Power Consumption (W)

EX2200-24T-4G: EX2200-24T-4G-DC:	50
EX2200-48T-4G:	76
EX2200-24P-4G:	470
EX2200-48P-4G:	96

Acoustic noise (dB)

EX2200-24T-4G: EX2200-24T-4G-DC: EX2200-24P-4G:	32.7
EX2200-48T-4G:	33.5
EX2200-48P-4G:	38.1

Performance

Switching Bandwidth (Gbit/s)

EX2200-24T-4G: EX2200-24T-4G-DC: EX2200-24P-4G:	56
EX2200-48T-4G: EX2200-48P-4G:	104

Forwarding Rate (Mp/s)

EX2200-24T-4G: EX2200-24T-4G-DC: EX2200-24P-4G:	42
EX2200-48T-4G: EX2200-48P-4G:	77

MAC Address Table (entries)

16,000

ARP Table (entries)

2000

Layer 2 Features

VLAN

IEEE 802.1Q: 1024; GVRP; QinQ (with EX-EFL license); VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP; ERPS (G.8032)

Multicast

IGMP snooping:	v1/v2/v3 (with EX-EFL license)
IGMP groups:	1000
Multicast VLAN (MVR):	Supported (with EX-EFL license)
Multicast Routing:	PIM-DM; PIM-SM; PIM-SSM (with EX-EFL license)

Layer 3 features

Routing Table (routes)

IPv4:

6500

IP Routing

Static Routing; RIPv1/2; OSPFv2 (with EX-EFL license); BFD (with EX-EFL license)

MPLS / VPN

Not supported

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Not supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; Syslog; NTP; Junos XML

Power Supply Unit (PSU)

AC PSU

Type:	Built-in
Quantity:	1
Rated voltage range:	110 VAC to 240 VAC, 50-60 Hz

DC PSU

Type:	Built-in
Quantity:	1
Rated voltage range:	-48 to -60 VDC

PoE (Power over Ethernet)

Supported by:	EX2200-24P-4G; EX2200-48P-4G
PoE (802.3af) (15W per port):
EX2200-24P-4G:	24 ports
EX2200-48P-4G:	27 ports

PoE+ (802.3аt) (30W per port):
EX2200-24P-4G: EX2200-48P-4G:	13 ports

PoE++ (802.3bt) (60W per port):	Not supported

PoE++ (802.3bt) (90W per port)	Not supported

Compatible Expansion Cards

Not supported

EX2200 Datasheet (en)
