Switches Juniper QFX5100 Series

Switches Juniper QFX5100 Series Available to Quote:

QFX5100-48S-AFO; QFX5100-48S-AFI

QFX5100-48S-DC-AFO; QFX5100-48S-DC-AFI

QFX5100-48S-3AFI; QFX5100-48S-3AFO

QFX5100-48S-D-3AFI; QFX5100-48S-D-3AFO

QFX5100-48T-AFI; QFX5100-48T-AFO

QFX5100-48T-DC-AFI; QFX5100-48T-DC-AFO

QFX5100-24Q-AFI; QFX5100-24Q-AFO

QFX5100-24Q-3AFI; QFX5100-24Q-3AFO

QFX5100-24Q-DC-AFI; QFX5100-24Q-DC-AFO

QFX5100-24Q-AA-AFI; QFX5100-24Q-AA-AFO

QFX5100-24Q-D-3AFI; QFX5100-24Q-D-3AFO

QFX5100-96S-AFI; QFX5100-96S-AFO

QFX5100-96S-DC-AFI; QFX5100-96S-DC-AFO

Request a Quote

Description Specifications Additional materials

Distribution Layer Manageable Switches with a high density of 10G and 40G ports

General All

Interfaces

QFX5100-48S-AFI/AFO:	48-Port 1/10GbE (SFP/SFP+); 6-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-48S-DC-AFI/AFO:	48-Port 1/10GbE (SFP/SFP+); 6-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-48S-3AFI/AFO:	48-Port 1/10GbE (SFP/SFP+); 6-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-48S-D-3AFI/AFO:	48-Port 1/10GbE (SFP/SFP+); 6-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-48T-AFI/AFO:	48-Port 100MbE/1GbE/10GbE (RJ45); 6-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-48T-DC-AFI/AFO:	48-Port 100MbE/1GbE/10GbE (RJ45); 6-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-24Q-AFI/AFO:	24-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 2 Expansion slots 1-Port console (RJ45); 1-Port USB
QFX5100-24Q-DC-AFI/AFO:	24-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 2 Expansion slots 1-Port console (RJ45); 1-Port USB
QFX5100-24Q-3AFI/AFO:	24-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 2 Expansion slots 1-Port console (RJ45); 1-Port USB
QFX5100-24Q-AA-AFI/AFO:	24-Port 40GbE (QSFP+); 2-Port out-of-band management (1GbE (RJ45) + 1GbE (SFP)); 1 Double-wide expansion slot 1-Port console (RJ45); 1-Port USB
QFX5100-24Q-D-3AFI/AFO:	24-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 2 Expansion slots 1-Port console (RJ45); 1-Port USB
QFX5100-96S-AFI/AFO:	96-Port 1/10GbE (SFP/SFP+); 8-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB
QFX5100-96S-DC-AFI/AFO:	96-Port 1/10GbE (SFP/SFP+); 8-Port 40GbE (QSFP+); 3-Port out-of-band management (1GbE (RJ45) + 2 x 1GbE (SFP)); 1-Port console (RJ45); 1-Port USB

Physical Parameters

Dimensions (HxWxD) (mm)/(in)

QFX5100-48S-AFI/AFO: QFX5100-48S-DC-AFI/AFO: QFX5100-48S-3AFI/AFO: QFX5100-48S-D-3AFI/AFO: QFX5100-48T-DC-AFI/AFO: QFX5100-24Q-AFI/AFO: QFX5100-24Q-DC-AFI/AFO: QFX5100-24Q-3AFI/AFO: QFX5100-24Q-D-3AFI/AFO: QFX5100-24Q-AA-AFI/AFO:	43.7 (1U) x 440.9 х 520.2 (1.72 (1U) x 17.36 x 20.48)
QFX5100-48T-AFI/AFO:	43.7 (1U) x 440.9 х 545.4 (1.72 (1U) x 17.36 x 21.47)
QFX5100-96S-AFI/AFO: QFX5100-96S-DC-AFI/AFO:	88 (2U) x 440.9 х 570 (3.46 (2U) x 17.36 x 22.44)

Maximum Weight (kg)/(lbs)

QFX5100-48S-AFI/AFO: QFX5100-48S-DC-AFI/AFO: QFX5100-48S-3AFI/AFO: QFX5100-48S-D-3AFI/AFO:	9.9 (21.8)
QFX5100-48T-AFI/AFO: QFX5100-48T-DC-AFI/AFO:	11.2 (24.8)
QFX5100-24Q-AFI/AFO: QFX5100-24Q-DC-AFI/AFO: QFX5100-24Q-3AFI/AFO: QFX5100-24Q-D-3AFI/AFO: QFX5100-24Q-AA-AFI/AFO:	9.8 (21.6)
QFX5100-96S-AFI/AFO: QFX5100-96S-DC-AFI/AFO:	14.74 (32.5)

Environmental Conditions

Relative Humidity (%)

5 to 90

Operating Temperature (°C)/(°F)

0 to 40 (32 to 104)

Maximum Power Consumption (W)

QFX5100-48S-AFI/AFO: QFX5100-48S-DC-AFI/AFO: QFX5100-48S-3AFI/AFO: QFX5100-48S-D-3AFI/AFO:	150
QFX5100-48T-AFI/AFO: QFX5100-48T-DC-AFI/AFO:	335
QFX5100-24Q-AFI/AFO: QFX5100-24Q-DC-AFI/AFO: QFX5100-24Q-3AFI/AFO: QFX5100-24Q-D-3AFI/AFO:	161
QFX5100-24Q-AA-AFI/AFO:	175
QFX5100-96S-AFI/AFO: QFX5100-96S-DC-AFI/AFO:	263

Acoustic noise (dB)

Performance

Switching Bandwidth (Tbit/s)

QFX5100-48S-AFI/AFO: QFX5100-48S-DC-AFI/AFO: QFX5100-48S-3AFI/AFO: QFX5100-48S-D-3AFI/AFO: QFX5100-48T-AFI/AFO: QFX5100-48T-DC-AFI/AFO:	1.44
QFX5100-24Q-AFI/AFO: QFX5100-24Q-DC-AFI/AFO: QFX5100-24Q-3AFI/AFO: QFX5100-24Q-D-3AFI/AFO: QFX5100-24Q-AA-AFI/AFO: QFX5100-96S-AFI/AFO: QFX5100-96S-DC-AFI/AFO:	2.56

Forwarding Rate (Bp/s)

QFX5100-48S-AFI/AFO: QFX5100-48S-DC-AFI/AFO: QFX5100-48S-3AFI/AFO: QFX5100-48S-D-3AFI/AFO: QFX5100-48T-AFI/AFO: QFX5100-48T-DC-AFI/AFO:	1.08
QFX5100-24Q-AFI/AFO: QFX5100-24Q-DC-AFI/AFO: QFX5100-24Q-3AFI/AFO: QFX5100-24Q-D-3AFI/AFO: QFX5100-24Q-AA-AFI/AFO: QFX5100-96S-AFI/AFO: QFX5100-96S-DC-AFI/AFO:	1.44

MAC Address Table (entries)

288,000 (l2-heavy-one mode)

ARP Table (entries)

48,000

Layer 2 Features

VLAN

IEEE 802.1Q: 4094; GVRP; QinQ; VLAN Translation

Layer 2 Reliability

STP/RSTP/MSTP/PVSTP; ERPS (G.8032)

Multicast

IGMP snooping:	v1/v2/v3
IGMP groups:	4091
Multicast VLAN (MVR):	Supported
Multicast Routing:	PIM-SM; MSDP

Layer 3 Features

Routing Table (routes)

IPv4:	128,000
IPv6:	64,000

IP Routing

Static Routing; RIPv1/2; OSPFv2; IS-IS (with license); BGP (with license); VRRP; BFD

MPLS / VPN

Supported (with license). MPLS LDP; L2VPN; MPLS-TE; L3VPN; GRE

Security

Local AAA:	Supported
RADIUS, TACACS+:	Supported
DHCP Server:	Supported
DHCP Relay option82:	Supported
DHCP Snooping:	Supported
Loop detection:	Supported
IP Source Guard:	Supported
Bandwidth Limit:	Supported
Broadcast, multicast, unknown unicast suppression:	Supported

Management

Telnet; SSH; LLDP; sFlow; SNMP v1/v2/v3; Syslog; NTP; Junos XML; Python

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	110 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:	2
Rated voltage range:	-36 to -72 VDC

PoE (Power over Ethernet)

Not supported

Compatible Expansion Cards

Model Number	Description
EX4600-EM-8F:	8-Port 1/10GbE (SFP/SFP+)
QFX-EM-4Q:	4-Port 40GbE (QSFP+). Only supported by QFX5100-24Q
QFX-PFA-4Q:	4-port 40GbE (QSFP+). Only supported by QFX5100-24Q-AA
