HD Camera Huawei VPC600 Series
HD Camera Huawei VPC600 Series Available to Quote:

VPC600

VPC620-4X

VPC620-12X

 Request a Quote
Description Specifications Additional materials

HD camera for videoconferencing

General All
Interfaces
1
VPC620:
  • 1-Port HD-VI (DVI 1.0 & YPbPr);
  • 1-Port RS-232C
VPC620-4X:
  • 1-Port HD-VI (DVI 1.0 & YPbPr);
  • 1-Port 3G-SDI (SMPTE-424M);
  • 1-Port RS-232C
VPC620-12X:
  • 1-Port HD-VI (DVI 1.0 & YPbPr);
  • 1-Port 3G-SDI (SMPTE-424M);
  • 1-Port RS-232C
2
Physical Parameters
3
Dimensions (HxWxD) (mm)

157 x 234 х 163

(6.18 x 9.21 x 6.42 in)

4
Maximum Weight (kg)

1.7 (3.75 lbs)

5
Environmental Conditions
6
Relative Humidity (%)

0 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)

20

9
Video Output
10

1080p 50/60; 1080i 50/60; 1080p 25/30; 720p 50/60

11
Lens Specifications
12
Sensor

2,38MP 1/2.8" CMOS

13
Zoom
VPC600:
Optical: 12х
Digital: 12х
VPC620-4X:
Optical: 4х
Digital: 2,5х
VPC620-12X:
Optical: 12х
Digital: 12х



14
Focal Length (mm)
VPC600: f = 3.9 to 46.8
VPC620-4X: f = 3.9 to 15.6
VPC620-12X f = 3.9 to 46.8
15
Lens Aperture

F1.8

16
Maximum Field of View
Horizontal: 72°
Vertical: 44.5°
17
Pan / Tilt
18
Pan range: ±100º
Tilt range: ±30º
Minimum pan range: 2º/s
Maximum pan range: 80º/s
Minimum Tilt range: 2º/s
Maximum Tilt range: 25º/s

19
Power Supply Unit (PSU)
20
AC PSU
Type: External
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
Output: 12 VDC



21
DC PSU

Not supported

22

VPC600 Datasheet (en)
