HD Endpoint Huawei TE30

HD Endpoint Huawei TE30 Available to Quote:

TE30

Request a Quote

Description Specifications Additional materials

HD endpoint for videoconferencing. Includes camera, microphone, HD codec

General All

Interfaces

Video interfaces:	1-Port VGA (IN); 1-Port VGA/YPbPr (OUT); 1-Port HDMI (OUT)
Audio interfaces:	1-Port 3.5mm line-in (IN); 1-Port HD-AI (stereo, connect to voicepanel); 1-Port 3.5mm line-out (OUT); 1-Port HDMI
Network interfaces:	1-Port 10/100MbE (RJ45) Internal Wi-Fi module
Common interfaces:	1-Port USB 2.0

Physical Parameters

Dimensions (HxWxD) (mm)

157 x 235 х 167

(6.18 x 9.25 x 6.57 in)

Maximum Weight (kg)

2.1 (4.63 lbs)

Environmental Conditions

Relative Humidity (%)

0 to 95

Operating Temperature (°C)

0 to 40 (32 to 104 °F)

Maximum Power Consumption (W)

Video Output

1080p 30; 720p 50/60; 720p 25/30; 4SIF / 4CIF; SIF / CIF / QSIF / QCIF / SQSIF / SQCIF

Supported protocols

ITU-T H.323; IETF SIP; H.221; H.225; H.230; H.231; H.235; H.241; H.242; H.243; H.245; H.281; H.350; H.460; T.140; DTMF, TCP/IP; FTP; FTPS; DHCP; SNMP; Telnet; SSH; HTTP; HTTPS with SSL/TLS; PPPoE; RTP; RTCP; SNTP; ARP; 802.1X; 802.1P; 802.1Q

Supported codecs

Voice codecs:	G.711; G.722; G.728; G.722.1; G.722.1C; AAC-LD; HWA-LD; G.719; G729; G.729A
Video codecs:	H.263; H.263+; H.264 BP; H.264 HP; H.264 SVC; RTV

Lens Specifications

Sensor

2MP 1/3" CMOS

Zoom

Optical:

12х

Maximum Field of View

Horizontal:

72°

Pan / Tilt

Pan range:	±100º
Tilt range:	±30º

Power Supply Unit (PSU)

AC PSU

Type:	External
Rated voltage range:	100 to 240 VAC, 50-60 Hz.
Output:	12 VDC

DC PSU

Not supported

TE30 Datasheet (en)
