IP PBX Grandstream UCM6200 Series

IP PBX Grandstream UCM6200 Series Available to Quote:

UCM6202; UCM6204;

UCM6208

Request a Quote

Description Specifications Additional materials

The UCM6200 series IP PBX appliance combines enterprise-grade voice, video, data, and mobility features in an easy-to-manage solution.

General All

Interfaces

UCM6202:	2-Port FXS (RJ11); 2-Port FXO (RJ11); 2-Port 1GbE (RJ45) PoE; 1-Port USB; 1 SD card slot
UCM6204:	2-Port FXS (RJ11); 2-Port FXO (RJ11); 2-Port 1GbE (RJ45) PoE; 1-Port USB; 1 SD card slot
UCM6208:	2-Port FXS (RJ11); 8-Port FXO (RJ11); 2-Port 1GbE (RJ45) PoE; 1-Port USB; 1 SD card slot

Physical Parameters

Dimensions (HxWxD) (mm)

UCM6202: UCM6204:	34.5 x 226 x 155 (1.33 x 8.89 x 6.10 in)
UCM6208:	44 (1U) x 440 x 185 (1.73 (1U) x 17.32 x 7.28 in)

Maximum Weight (kg)

UCM6202: UCM6204:	0.51 (1.12 lbs)
UCM6208:	2.23 (4.40 lbs)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)

0 to 45 (32 to 113°F)

Maximum Power Consumption (W)

Supported protocols

TCP/UDP/IP, RTP/RTCP, ICMP, ARP, DNS, DDNS, DHCP, NTP, TFTP, SSH, HTTP/HTTPS, PPPoE, SIP (RFC3261), STUN, SRTP, TLS, LDAP, HDLC, HDLC-ETH, PPP.

Supported codecs

Voice codecs:	G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC, GSM, AAL2-G.726-32, ADPCM; T.38
Video codecs:	H.264, H.263, H263+

Maximum subscribers

Management

Web

Power Supply Unit (PSU)

AC PSU

DC PSU

Type:	PoE (802.3af)
Rated voltage range:	48 VDC
