IP Phones Grandstream GXP1780/1782 Series

IP Phones Grandstream GXP1780/1782 Series Available to Quote:

GXP1780;

GXP1782

Request a Quote

Description Specifications Additional materials

The GXP1780/1782 are powerful mid-range IP phones with advanced telephony features.

General All

Interfaces

GXP1780:	2-Port 10/100MbE (RJ45) PoE; 1-Port headset jack (allowing EHS with Plantronics headsets) (RJ9)
GXP1782:	2-Port 1GbE (RJ45) PoE; 1-Port headset jack (allowing EHS with Plantronics headsets) (RJ9)

Physical Parameters

Dimensions (HxWxD) (mm)

86 x 231 х 167

(3.4 x 9.09 x 6.6 in)

Maximum Weight (kg)

0.925 (2.04 lbs)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)

0 to 40 (32 to 104 °F)

Maximum Power Consumption (W)

Screen

Backlit LCD display

Resolution: 200x80.

Supported protocols

SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS(A record, SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPV6.

Supported codecs

G.711u/a-law, G.722 (wide-band), G.729A/B, G.726, G.723.

Power Supply Unit (PSU)

AC PSU

Type:	External
Rated voltage range:	100 to 240 VAC, 50-60 Hz
Output:	5 VDC, 0.6 А

DC PSU

Type:

PoE (802.3af)

GXP1780 / GXP1782 Datasheet (en)
